Ball bearing slides

Load: 0 kg - 28 kg
Stroke: 210 mm - 370 mm

Telescopic slides GN 1400 are installed vertically and in pairs. The stroke reaches ≈ 75 % of the nominal length l1 (partial extension). With type A without rubber stop, the end stops are made out of steel, which prevents ...

Load: 0 kg - 325 kg
Stroke: 298 mm - 1,504 mm

Telescopic slides GN 1440 are installed vertically and in pairs. The stroke reaches ≈100 % of the nominal length l1 (full extension). Patented plastic ball cages ensure extremely smooth running of the ...

Stroke: 600 mm - 1,200 mm
Length: 300 mm - 600 mm
Width: 45.4 mm

Stainless steel telescopic slides GN 1450 are installed vertically and in pairs. The stroke reaches ≈ 100 % of the nominal length l1 (full extension). The telescopic slides are delivered in pairs. ...

Stroke: 50 mm

Loctite 97118 Dispensing - Advancing Slide with stroke 50mm The Advancing Slide System consists of a double acting, dual piston cylinder. The mounting bracket eases a precise positioning of either dispensing ...

Load: 3.8 kg - 33.7 kg
Stroke: 100, 200, 150, 50, 25 mm

• 2x8mm, 2x16 or 2x20mm bore. • With or without shock-absorbers. • Double-acting drive. • Very favorable performance/price ratio. • Optional magnetic sensors. Manufacturer: Gimatic

Load: 1 kg - 11.2 kg
Stroke: 10, 20, 30 mm

• 6, 10 or 16 mm bore. • Various fastening options. • Double-acting drive. • Internal elastic bumpers. • Optional magnetic sensors. Manufacturer: Gimatic

Load: 45.9 kg
Stroke: 35 mm

• Single-acting intermediate stop. • 36mm clamp for GN-10 actuator. • Used for the extraction of bumpers. • Optional magnetic sensors. • Stroke reduction spacer included.

... components • Range in open or closed bearing design Linear slides bearing for manual movement are based on linear ball bearings with self-aligning ...

Stroke: 10 mm - 200 mm
Working temperature: -10 °C - 80 °C
Displacement speed: 0.8 m/s

Flat, compact precision slides with two cylinders. The fixed and moving parts are moved by a sturdy ball recirculation carriage running on hardened guides. Elastic mechanical stop or shock absorbers are ...

Load: 78 kg - 100 kg
Stroke: 340 mm - 733 mm
Length: 300 mm - 700 mm

Telescopic slides, steel for side mounting, over-extension, load capacity up to 100 kg Material: Slides steel. Ball cages steel. Balls, steel. Version: Slides ...

Stroke: 232 mm - 966 mm

Telescopic rails, double-T form Material: Rail and race ball-bearing steel. Balls, ball-bearing steel. Ball cage steel. Version: Rail, ...

Load: 13 kg - 20 kg

Telescopic slides, steel for side mounting, full extension, load capacity up to 20 kg Material: Slides steel. Ball cages steel. Balls, steel. Version: Slides ...

Load: 25 kg
Stroke: 50 mm - 1,000 mm
Width: 40 mm

Series:FSK40J Type:Ball Screw Stroke Range:1000mm Position Accuracy:0.02mm Max Speed:200mm/s Max Load:25kg Technical Feature Original Non-rail Design. Smaller, Thinner, Stronger. Installing it Upside Down is ...

Length: 96, 126 mm

With recirculating ball guide Clamping surface plane milled M6 T-key inserts Central lubrication option Suitable for linear guide LFS-8-1 and LFS-8-2 Adjustable for no play L 96 x W 72 x H 28,5 mm (WS 1/70) L 126 ...

With recirculating ball guide Clamping surface plane milled Suitable for linear guide LFS-12-1 and LFS-12-2 Adjustable for no play Versions: standard or stainless steel version Length: 94 or 124 mm

Load: 0.8 lb
Stroke: 0.3 in

Ball Slide Assemblies - Inch Family: C Model: C-.5 Price: $ 95.00 - Clear Anodize - Standard The standard finish is a clear anodize carriage and black anodize base. Black anodize carriage and ...

Load: 1.5 lb
Stroke: 0.5 in

Ball Slide Assemblies - Inch Family: C Model: C-.5 Price: $ 95.00 - Clear Anodize - Standard The standard finish is a clear anodize carriage and black anodize base. Black anodize carriage and ...

Load: 8 lb
Stroke: 1 in

Ball Slide Assemblies - Inch Family: D Model: D-2 Price: $ 83.00 - Clear Anodize - Standard The standard finish is a clear anodize carriage and black anodize base. Black anodize carriage and ...

Load: 12 kg - 45 kg
Stroke: 147.5 mm - 554 mm

Load: 50 kg
Stroke: 140 mm - 711 mm

Load: 35 kg - 65 kg
Stroke: 304.5 mm - 698 mm

Load: 250 kg
Stroke: 471.4 mm

heavy duty, full extension ball-bearing slide (3 pieces), front disconnect and positive stop

Load: 43 kg
Stroke: 304.8 mm

3/4 extension ball-bearing slide (2 pieces), front disconnect

Load: 59 kg
Stroke: 378 mm

full extension ball-bearing slide (3 pieces), front disconnect and positive stop

Load: 109 kg
Stroke: 7.6 cm - 106.7 cm
Working temperature: -18 °C - 82 °C

... aluminum alloy carriage that runs in the dovetail ways of the base. Lead screws are constrained and supported with steel thrust bearings and snap ring retainer. The lead screw drive nut is a tension adjustable nut made ...

Load: 182 kg
Stroke: 7.6 cm - 99 cm
Working temperature: 0 °C - 180 °C

... aluminum alloy carriage that runs in the dovetail ways of the base. Lead screws are constrained and supported with steel thrust bearings and snap ring retainer. The lead screw drive nut is a tension adjustable nut made ...
