Class gPV fuses

Amperage: 2 A - 25 A

... are made on fuses for application in photovoltaic systems. These fuses have a high DC rated voltage and a tripping characteristic specially designed to protect PV modules and their connecting cables (the ...

Amperage: 50 A - 400 A
VDC: 1,500 V
Service temperature: -40 °C - 70 °C

... systems. Helio-Protection® HP15NH fuse links are designed for the protection of cables in a PV group of chains when a short circuit occurs in a panel (main fuse category). This HelioProtection® main fuse ...

Amperage: 10 A - 250 A
VDC: 400 V - 1,000 V
Breaking capacity: 5,000 A - 200,000 A

... indicators provide a clear message In the case of fuses installed in fuse switch rails, the reliable top indicators can often not be clearly seen. Therefore, a lot of time can be wasted looking for fuse-links ...

Amperage: 2 A
VDC: 1,000 V

The CH10 gPV series is made to protect photovoltaic modules. It has a breaking capacity of 10 kA DC or 3 0kA DC, with a 1000 V rated voltage. Models with standard and SU contacts are available. All units are is certified ...

Amperage: 20, 15, 10, 6 A
VDC: 1,500 V
Breaking capacity: 0 A - 10,000 A

Fuse for photovoltaic applications, for 10X85mm fuses. 10kA breaking capacity at 1500VDC, 6A •Type of product: Fuses for PV applications - 10x85mm •Type of operating voltage: DC •IEC ...

Amperage: 10,000 A - 30,000 A

DF ELECTRIC releases gPV Cylindrical fuses for photovoltaic applications and these are best used whenever no-load voltages above 800V DC are reached, thanks to the latest technological innovations. This ...

Amperage: 50 A - 400 A

When designing level 2 array junction connection boxes higher currents appear requiring NH knife fuse protection. We can use ultrarapi gR-IOOOVdc curve fuses that will protect against overload.

Amperage: 1 A - 30 A
VDC: 1,000 V

Code FUSPV731038 Description • 1000V DC, 10x38mm PV fuse link • Rated Current: 1-30 A • Rated Breaking Capacity: 30kA • Time Constant: 1-3ms • Special design with silver plated caps for high-power PV applications • ...

Amperage: 2 A - 50 A
VDC: 1,500, 1,000 V
Breaking capacity: 20,000 A

... requirements, and the company will design according to the requirements) Relative air humidity: less than 90% This series of the fuse is suitable for solar photovoltaic power generation system, rated voltage to1500V, ...

Amperage: 1 A - 630 A
VDC: 1,000, 1,500 V

Chordn photovoltaic(PV) fuses were engineered and designed specifically for the protection of photovoltaic systems. Its enhanced fuse construction makes it ideal for constant temperature and current cycling ...

Amperage: 400 A - 630 A
VDC: 1,500 V

NH3LgPV 1500V DC 400A-630A Photovoltaic Fuse Security Certificate:TUV Standard: IEC 60269-6, GB/T 13539.6 INTERRUPTING CAPACITY: 50,000 amperes at 1500V DC (Time Constant:1-3ms) Application: PV Inverters, Re-combiner ...

VAC: 0 V - 400 V
VDC: 0 V - 250 V

... tailor-made solutions consisting ofNH-switchgear, NH-fuse technology and electronics fromJEAN MÜLLER reliably perform their service day after day, aroundthe clock. Should an electrical fault occur, the fuses ...
