CNC boring mills

... switching. pick up is a special machining centre that in an instant can change over completely from whirling to milling operation due to an end milling spindle or angle head. pick up operates using the ...

X travel: 2,000, 2,500, 3,000, 4,000 mm
Y travel: 1,500, 2,000, 2,500 mm
Z travel: 1,500, 1,200, 1,600, 2,000 mm

A best-selling, popular machine series with sales in excess of 1,000 unitsachieved over the last decade. Continuous improvement and upgrades to the machine series’ build and technologies used, helps maintain its Number One position in ...

X travel: 1,400 mm
Y travel: 1,390 mm
Z travel: 1,100 mm

Efficiency and precision at the highest technical level Table Spindle nose - table center (mm)-0 - 1.555 Table working surface W x D (mm)-1.120 x 1.250 T-Slots (DIN 650)-7 x 24 x 160 Load max. (uniform distribution) (kg)-4.000 Spindle Spindle ...

X travel: 510 mm - 750 mm
Z travel: 800 mm
Power: 45, 37 kW

... ●Table speed：2～600min-1 ●Floor space：5080×3530mm （200×139in） ●Machine height：4432mm （174.5in） ●Mass of machine（including CNC system）： 11 000kg （24 200lbs） Mechanical structure to allow powerful cutting Main structure ...

X travel: 4,000, 2,000 mm
Y travel: 1,800, 1,500 mm
Z travel: 2,500, 3,000, 3,500, 4,000 mm

RONIN 300/400 is a horizontal travelling column milling machine able to accomplish a wide range of machining requirements for die & mould making, aerospace applications and general machining. Thanks to its innovative shape design and ...

X travel: 2,000 mm - 6,200 mm
Y travel: 2,000, 1,800, 1,650, 1,600, 2,500 mm
Z travel: 1,400, 1,200, 2,000, 1,700 mm

The HBW series from KAAST is a collection of CNC horizontal boring mills that feature either a fixed or moving column design paired with hardened and ground guideways. These machines ...

X travel: 2,000 mm
Y travel: 1,800 mm
Z travel: 1,300 mm

Power and endurance for heavy jobs demanding accuracy and high productivity. The HB1416 is a horizontal boring mill featuring a solid cast iron base, cylindrical roller guides, and backlash-free design ...

X travel: 3,200 mm - 8,500 mm
Y travel: 2,700, 3,200, 3,600 mm
Z travel: 1,000, 1,250 mm

Gantry framework whole gantry milling and boring machine inherited the characteristics of the traditional gantry machine with strong infrastructure rigidity, symmetrical structure, strong stability, on ...

Y travel: 2,500 mm - 12,000 mm
Z travel: 1,250 mm - 2,000 mm
W travel (spindle): 1,000 mm - 1,800 mm

... the FEM analysis. A complete range of advanced milling attachments heads provides the optimum solution for each user’s application requirements. Attachment heads The Aries Series milling and boring ...

... 0,14mm auf Ø100mm With step motor 4.2 Amp. Scope of delivery without jaw chuck Pros Can be fixed horizontal at the milling table. Closed execution avoid ingression of span. Harded and smoothed spindle.

Spindle diameter: 100, 110 mm
Power: 29.3, 19.5, 46.5, 31 kW

Medium size table-type horizontal boring mill, with longitudinal travel of the column and cross-wise travel of the table. Designed for machining of workpieces of up to 10 tons. Optional version with ...

X travel: 6,000 mm - 30,000 mm
Y travel: 3,000 mm - 4,500 mm
Z travel: 1,500 mm

... materials up to any single components in the machine (mechanic, electronic, software, devices). The final product is a MILLING-BORING CENTER finalised to achieve : the maximum accuracy in working environments with ...

X travel: 5,000, 3,000, 4,000 mm
Y travel: 2,500, 3,000, 2,000 mm
Z travel: 2,500, 3,000, 2,000 mm

... Extended Ram Headstock: The Boring Spindle exceeds the center of the table by nearly 300mm The Head A UA 360 “GradoGradoexceeds the center of the table both in the horizontal and vertical position. Boring ...

X travel: 1,600 mm
Y travel: 1,220 mm
Z travel: 900, 1,710 mm

... is a contouring table type of a horizontal boring machine designed by the company RETOS VARNSDORF s. r. o. It is an option to the manually operated machine W100A. Features contouring horizontal boring ...

X travel: 2,000 mm - 4,200 mm
Y travel: 2,000 mm
Z travel: 2,000 mm

X travel: 4,000 mm
Y travel: 2,600, 3,200 mm
Z travel: 1,000 mm

Improved flexibility and high dynamics for enhanced performance Multitasking machine: milling and turning solution in a single set-up SORALUCE head technology: highly reliable, extensive range of SORALUCE quills ...

X travel: 2,000 mm
Y travel: 1,700 mm
Z travel: 1,400 mm

... driven by a gearbox. 0.001° indexing rotary table. Linear scales on X, Y, Z-axis. 40 tools chain type magazine. FANUC 0iMD CNC control.

X travel: 2,000, 3,000, 4,000 mm
Y travel: 1,800, 2,300, 3,000 mm
Z travel: 1,600 mm

Our table-type boring machining mill centers include various custom-made accessories, such as a 40-ton load rotary table, pallet changer, and milling head.

X travel: 1,600 mm
Y travel: 1,200 mm
Z travel: 1,000 mm

The ZENTRUM-200Q horizontal boring and milling machine is designed to handle heavy-duty machining tasks. This machine could be configured with Fanuc, Heidenhain, Siemens, or Mitsubishi controls for the most friendly ...

Power: 100 kW - 300 kW

The PowerTurn CNC vertical boring mill is the largest and most powerful of our VTL machine line, tailor-made to tackle projects of immense scope and complexity, such as internal and external ...

Horizontal milling and boring machines WHN 110/130 are strong, powerful representatives of the advanced generation of TOS VARNSDORF a.s. machines, meeting the needs of modern progressive technology. The ...

... travel 2000 Column Front/Back travel 4000 Slider/spindle feed speed 0.5-4800 Column Front/Back feed speed 1-5600 Miling/boring head up/down feed speed 1-5600 Main motor power 30

X travel: 2,000, 2,500 mm
Y travel: 1,500, 2,000 mm
Z travel: 1,200, 1,500 mm

A best-selling, popular machine series with sales in excess of 1,000 units achieved over the last decade. Continuous improvement and upgrades to the machine series’ build and technologies used, helps maintain its Number One position in ...

X travel: 2,000 mm
Y travel: 1,500, 1,800 mm
Z travel: 1,400 mm

STANDARD ACCESSORIES: Linear scales on X,Y,Z axes, Spindle oil cooler Automatic power off , Hydraulic system Coolant system, Lubricator system Alarm lamp, Work lamp M.P.G., RS232 interface Heat exchanger, Chip conveyor and ...
