Compact connectors

Primary current: 40 A
Voltage: 1,000 V

The PCIH series is a part of the Compact Power family featuring Plug-in power interface for CompactPCI and other platforms. PCIH series are 91mm (female) CompactPCI connectors - High current through ...

Primary current: 4 mA - 20 mA
Operating temperature: -40 °C - 100 °C

A rugged and compact connector that meets all the requirements of aggressive environments (moisture, corrosion, pollution) in both industrial and road infrastructure applications. PNC ...

Primary current: 16 A
Voltage: 400, 250 V

The RST® MINI logically follows the trend toward compact designs. With its small dimensions, this installation connector can also be used in extremely confined spaces. ...

... able to connect two ethernet patch leads, allowing more distance and freedom from wall sockets or connecting devices. Compact and robust, the socket to socket RJ45 adapter also features gold plated contacts for assured ...

Operating temperature: -25 °C - 70 °C

This product is a small water-proof simplex SC connector. With a built-in SC connector core, its plastic enclosure is resistant to high and low temperatures, acid and alkali corrosion, ...

Primary current: 10, 18, 16 A
Voltage: 600, 430, 250 V

... gases, mists or vapours or combustible dusts. With an IP68 ingress protection rating, these robust explosion proof electrical connectors are also ideal for harsh environments that require secure, watertight and environmentally ...

... escies.org. The Mini AVIM® connector has been developed after market request of a smaller and lighter version of our acclaimed AVIM® connector for harsh environment, especially space ...

... reinforced outer walls of the multipole connector allow a high degree of robustness. miniaturized, compact design straight and angled connectors many pincounts available variable ...

Primary current: 10, 16, 32 A
Voltage: 440, 250 V
Operating temperature: -40 °C - 60 °C

... IC-CPD) and other vehicle charging system. Comply with GB / T20234.1-2015 and GB / T20234.2-2015. Ergonomic design, compact, streamlined shape, beautiful appearance, convenient and safe operation, and excellent ...

... coolers One piece machined body: compact space and lightweight Designed for maximum performance: 100% production leak tested Improved ergonomics and cleanliness: with rounded corners Controlled axial clearance: prevents ...

... interface of lightning protection zone or in the computer room, and is mainly used as the collection bar for grounding cable. •Compact structure, easy installation, pleasant appearance •Anti-collision plastic is adopted

Primary current: 3 A
Voltage: 50 V

The miniCON with its flexible and compact design is perfectly suitable for multipin/industrial applications. The rugged all metal miniature connector offers a push-pull ...

... temperature range from –51°C to +125°C 3 – 55 connectors (Push‐Pull), 3 – 37 connectors (Break‐Away) High‐speed data technology 6 sizes (Push‐Pull), 5 sizes (Break‐Away) Flexible, reliable, and ...

Primary current: 100 A

HIGH DENSITY POWER AND SIGNAL CONNECTOR SYSTEM The PwrMAX® connector family offers a compact means for connecting up to 100A DC power in modern system archictures requiring high ...

Primary current: max 3.0 A
Voltage: 150 V - 600 V

... for micro-D connectors. These miniature connectors meet the requirements of the most demanding applications and harsh environments. Despite their high pin density, small size and lightweight ...

Metal Waterproof Push Pull Self-locking Connector U series has same insualtor and contact configuration as F series: 1.Secure high performance push pull self-locking system 2.Compact design and ...

Operating temperature: -40 °C - 107 °C

... manufactures both standard and custom hermetic D-sub connectors for various applications and industries. The 57382 design is a compact D-sub 9 position feedthrough with a vacuum face seal. The D-sub connector ...

Primary current: 2 A
Voltage: 60 V

Product information "Connector FR4 for 1 x COB LED array 20 x 24 mm" Prefixation of the COB Compact, low overall height: 2.4 mm Equipped with SMD terminal block 46.132.1001.50 with wire release function Integretad ...

Operating temperature: -40 °C - 85 °C

NanoPlug™ is an ultra compact, metallic optical connector that is 1/10 smaller than a LC connector and does not require a splice tray while also exhibiting thermal resistance. The NanoPlug™ ...

Data rate: 10 Gb/s
Operating temperature: -40 °C - 70 °C

... to 10 GbE. For industrial applications, building cabling and applications in the field of building management systems. The compact design with detachable wire separator ensures simple, safe, tool-free installation on ...

Primary current: 5 A
Voltage: 250 V
Operating temperature: -40 °C - 80 °C

... aviation plug connector Precision development waterproof connection concentration CNLINKO LP-16 waterproof connector Multiple applications waterproof solution Strictly selection CNLINKO 's LP-16 ...

Impedance: 50 Ohm
Voltage: 335 V
Pitch: 0.25 in

... solder/solder. The NEX10 connector system meets the existing and future infrastructure efficiency demands of small cell applications and 5G mobile networks. For frequencies up to 20GHz, the new robust ...

Primary current: 0.3, 3 A
Voltage: 50 V
Pitch: 0.3 mm

... as connectors. For smartphones, mounting space of connectors are becoming more high-density due to the increasing number of camera modules. To cater to these needs, JAE has launched the 1.6 mm width ...

Primary current: 5 A
Voltage: 500 V
Pitch: 1.27 mm

Application - Card Connector - Board to Board Familytype - Memory Technology - Compact Flash Pitch - NULL Smt - no Insulation resistance - 1000 MOhms min. Number of circuits - 50 Compliant with ...
