Compact valves

Pressure: 0 bar - 8 bar
Flow rate: 1,600, 350 l/min

... resolution Battery operation possible Lightweight and compact design of the control valve Tecno easy is the entry-level variant of HOERBIGER's product portfolio of piezo-controlled proportional valves.

DN: 0.5 in
Pressure: 3 bar - 10 bar
Temperature: -10 °C - 80 °C

... the adjustment needle valve. The piston opens the main valve when the downstream side of the valve reaches approximately 60% of the supply pressure. The ramp up time to reach the switch-over ...

DN: 5 mm
Pressure: 0.5 bar - 10 bar
Temperature: 5 °C - 75 °C

2/2-way, latching cartridge valve with a nominal orifice DN 5 with a mechanical valve actuation. By manual operation, at a push of a button so to speak, the valve opens and closes. The ...

Pressure: 400 bar
Temperature: -20 °C - 90 °C
Flow rate: 250, 180, 400 l/min

The KLSV is a series of flow-sharing, load-sensing main control valves for multifunction construction machinery. Their low hysteresis and excellent pressure drop characteristics provide superior performance and efficiency. > ...

Temperature: 5 °C - 150 °C

Series XLA-2 are high vacuum angle valves for use in industrial applications employing high vacuum and process gases. Common industries that may use these angle valves include semiconductor, solar and ...

DN: 0.5 in - 2 in
Temperature: 14 °F - 356 °F

Save space while maintaining flow rates with the compact Series SAV-BT Angle Seat Valve. The pneumatic, externally piloted angle seat valve is operated by a single acting actuator with ...

DN: 0 mm - 1,200 mm
Pressure: 0 bar - 830 bar
Temperature: -196 °C - 570 °C

Control valve manufacturing started in 1960 under the brand of Nuovo Pignone and since then, its technology has been continuously improved. With over 160.000 valves installed worldwide, compliant with ...

DN: 10 mm - 50 mm
Pressure: 25 bar
Temperature: 0 °C - 120 °C

... the SAUTER Valveco compact regulating valve provides correct supply to the consumers and a reduction of temperature variations in the room, so that the use of energy is more accurate and more efficient. Features Regulating ...

DN: 15 mm - 50 mm
Pressure: 4 bar
Temperature: -20 °C - 80 °C

The pinch valves from Ross has a compact and economical design that is utilized for a broad range of applications in the industrial automation industries. It is ideally used for compressed air and other ...

DN: 10 mm - 80 mm
Pressure: 16 bar
Temperature: 0 °C - 60 °C

PTFE or PE ball seating joint Double sealed shaft Seal materials - EPDM, FPM Ball seating joint - PE, PTFE Connections - PE fusion socket, PE fusion spigot, solvent socket, solvent spigot, threaded socket Approvals ...

DN: 64.1 mm
Pressure: 207, 276 bar
Temperature: -40 °C - 204 °C

... cartridge type, combination valve including a fixed orifice, pressure compensated, priority type flow regulator and a pressure relief valve. Operation With inlet at port 1 and ports 4 and 2 connected ...

DN: 25 mm - 500 mm
Temperature: -273 °C - 450 °C

... synchronized with the safety valves -Complete, coordinated combination of one supplier with qualified resistance coefficients Bursting discs with safety valves in combination -Tight up to the set ...

DN: 25 mm - 100 mm
Pressure: 0 Pa - 1,000,000 Pa
Temperature: 0 °C - 95 °C

... customer-specific connection options. Product characteristics Hygienic, modular design - Maintenance-free switching valve - Safety and vacuum valves can be pneumatically vented - Materials ...

DN: 0.5 in - 2 in
Pressure: 60 psi - 90 psi

Compact Pneumatic Type-14 Diaphragm Valve The Type-14 diaphragm valve is available with an optional pneumatic actuator for operation via a pressurized air supply. The pneumatic actuator ...

DN: 0.5 in
Pressure: 100 psi
Temperature: 180 °F

The NIBCO® PEX mini ball valve is made of lead-free* Performance Bronze alloy. Because of its compact design, the mini ball valve is ideal for use in ...

Temperature: 50 °C

... in flood protection. Compact valve with self-contained frame design for wall mounting with anchors Vibration-free guiding of the gate over the entire travel; can be used in intermediate positions ...

DN: 15 mm - 65 mm
Pressure: 2 bar - 16 bar
Temperature: -10 °C - 180 °C

... Repeatability: < 1.0% FS Failsafe: valve closes (NC) in the event of voltage failure, optionally outlet fail freeze feature Control_valve_body: bronze, optionally SST 316L Cone_seal: PTFE Proportional_valve_body: ...

DN: 15 mm - 400 mm
Pressure: 55 bar
Temperature: -196 °C - 450 °C

... floating (seat supported) ball valves, incorporating mounting flanges to BS EN ISO 5211, featuring soft, metal and carbon seated designs There are two separate design types within the one piece Ultra-Seal range, depending ...

DN: 50, 25, 40, 16 mm
Pressure: 5 bar - 7 bar
Temperature: 200, 50, 250, 80 °C

The compact mini UHV gate valve featuring a modular actuator concept is well suited for industrial and R&D applications. It is often used in pipings of semiconductor process systems.

DN: 0.5 in - 2.5 in
Temperature: 105 °C

Overview The Roda Deaco RDS1 Swing Gate Valve is a compact air intake shutoff valve that provides emergency overspeed shutdown of a diesel engine. The RDS1 Swing Gate Valve ...

DN: 2 in - 10 in

... iron/epoxy coated, Class 125 Apollo InternationalTM 6PLF Series Lead Free* Ball Valves offer unobstructed turbulence-free flow that gate and butterfly valves can’t match. Compact design ...

DN: 70, 145 mm
Pressure: 400 bar - 2,800 bar
Flow rate: 0 l/min - 650 l/min

Pneumatically Switching Valve PSV The reliable switching valve for a wide range of requirements. Available open or closed without actuating energy. Special features: Switchable under operating pressure, ...

DN: 15 mm - 100 mm
Pressure: 16 bar
Temperature: -20 °C - 160 °C

A-BV1-F One-piece housing, short body, open passage, with flange connection to EN 1092-1 PN16, with flange for actuators to DIN / ISO 5211 Housing and ball made of 1.4408. Sealing material PTFE / glass fibre 15%. Temperature range -50 ° C to 200 ° C

DN: 0.75 in
Pressure: 10 bar
Temperature: 10 °C - 60 °C

• Exclusive use in drain circuits. • Connections to rigid pipe or PE flexible pipe. • Female threaded end connectors.

Dual Power Brake Valves for Steering Assist Easily Adapted to Dual Pedal Systems This design can easily adapt to many dual pedal systems to provide steering assist power braking with one pedal applied or full power ...
