Rotational speed: 7,000 rpm
Gripping force: 0.6 kN - 14 kN
Outer diameter: 210 mm - 315 mm
Quick Jaw Change Diaphragm Chucks Size Range: 8" - 12" (210mm - 315mm) Number of Jaws: 3 Jaws OD or Pitch Line Clamping Centrifugal Force Compensation Proofline Sealed Type D diaphragm ...
SMW AUTOBLOK
Outer diameter: 210 mm - 315 mm
Quick Jaw Change Diaphragm Chucks Size Range: 8" - 12" (210mm - 315mm) Number of Jaws: 3 Jaws Radial and Axial Clamping Flat Gripping Force Curve Proofline Sealed D-KOMBI Quick Jaw Change Diaphragm ...
SMW AUTOBLOK
Use: for second operations in turning, hardturning, grinding and checking Very good accuracy and repeatability Totallly sealed; maintenance-free Supplied with quick change top jaws TMCR (patented TOBLER system) that allows ...
Rotational speed: 15,000 rpm
Outer diameter: 3 in - 10 in
Northfield Diaphragm Chucks are the most accurate chucks in the world and are the fastest to open and close out of all of the chuck types (scroll, manual, hydraulic, ...
NORTHFIELD PRECISION INSTRUMENT
Shown here is a special, Northfield 3-jaw, 5” Diaphragm Chuck (DPH-500 type) with custom top tooling. Our customer requested a method to accurately grip their small (.098” OD) fuel injector plungers without ...
NORTHFIELD PRECISION INSTRUMENT
6” Diaphragm Chuck with non-metallic top tooling in contact with the customer’s part. Our customer manufactures these delicate, ceramic rings (shown in the foreground) and needed a way to carefully hold ...
NORTHFIELD PRECISION INSTRUMENT
... DPH1000W, 10-inch diaphragm chuck capable of locating and clamping two work pieces with different location data. Due to production requirements, end-user requested quick and accurate changeover between ...
NORTHFIELD PRECISION INSTRUMENT
... Northfield DPH-400 Diaphragm Chuck (.000010” TIR) with custom top tooling attached. Our customer needed a drawbar-actuated chuck to grip the O.D.’s of various parts they manufacture for ...
NORTHFIELD PRECISION INSTRUMENT
Outer diameter: 5 in
... precision workholding chucks, introduces their special 5 inch diameter diaphragm chuck with morse taper number three female bore for locators. The chuck has a built-in ...
NORTHFIELD PRECISION INSTRUMENT
Outer diameter: 4 in
DPH-400W (4-inch dia.) diaphragm chucks with special jaws and stops. The stops have (3) small "Air Detect" holes for part seating conformation. Air is pumped through these holes, and when the part rests ...
NORTHFIELD PRECISION INSTRUMENT
Outer diameter: 3 in
3M needed a chuck that repeated to 50 millionths and weighed less than 1.5 lbs. to check the efficiency of an electric motor that gets implanted in the body to pump an artificial heart. We made a 3-inch aluminum diaphragm ...
NORTHFIELD PRECISION INSTRUMENT
Outer diameter: 3 in - 18 in
Features: - Standard Air Chucks from 3" - 18" diameter - Featuring Self Contained Actuator - High Speed Functionality - Standard Jaws in Stock
NORTHFIELD PRECISION INSTRUMENT
Outer diameter: 6 in
This is a DPH-600 (6-inch diameter) Diaphragm Chuck used for super finishing (grinding for accurate flatness and parallelism) on the outer faces of the customer’s parts (not shown). This chuck ...
NORTHFIELD PRECISION INSTRUMENT
Rotational speed: 3,000 rpm - 8,000 rpm
Gripping force: 232 kgf - 12,486 kgf
Outer diameter: 80 mm - 294 mm
... Air is supplied to the chuck by a multi passage air tube assembly with a rotary coupling. Coolant through the spindle capability is standard. Application OD and ID chucking for cylindrical grinding, turning, ...
Microcentric
Rotational speed: 3,500 rpm - 7,000 rpm
Gripping force: 2,940 kgf - 19,600 kgf
Outer diameter: 102 mm - 294 mm
... cylinder mounted at the rear of the machine spindle. Application OD and ID chucking for cylindrical grinding, turning, and hard turning. Ideal for workpieces requiring high concentricity, and applications ...
Microcentric
Power Operated Wedge Hook Chuck With Pull-back Action And Centrifugal Compensation Power chucks type QLC-NZ are especially used for high accuracy requirements, in particular for high axial run-out ...
ITW Workholding
... accomplished in minutes. Diaphragm chucks contain no moving, wearable parts, eliminating downtime and maintenance costs. The Universal Gear Diaphragm Chuck provides ...
ITW Workholding
The Forkardt PLD (Pitch Line Membrane) membrane chuck is primarily designed for the series production of transmission components. The chuck offers a flexible solution for hard turning ...
ITW Workholding
The principle of the diaphragm chuck is based on simplicity. It works similar to a disc spring by elastic deformation of the chuck body. Since there are no sliding parts, there is also ...
ITW Workholding
Diaphragm chucks use compressed air to open and close the jaws holding workpieces on lathes. They offer improved accuracy and axial symmetry during turning operations.
ApplicationsDiaphragm chucks are primarily used for light-duty turning operations such as fine boring, facing and grinding. They are used on computer numeric control (CNC) lathes equipped with a compressed air system.
TechnologiesThe diaphragm chuck uses a compressed air piston or drawbar to open the diaphragm, allowing the workpiece to be mounted within the jaws. As the piston is retracted, the jaws close, holding the workpiece in place. The diaphragm is made of spring steel and the base of the jaws from hardened steel.
How to chooseBe sure to determine the approximate diameter of the workpiece when selecting a diaphragm chuck.
- Concentricity
- Fine turning
- Metal fatigue
