Electric motor couplings

Torque: 30 Nm - 48,600 Nm
Rotational speed: 1,200 rpm - 12,500 rpm

Torsionally flexible coupling for electric motor driven high-speed shaftsi The FLEXOMAX G is a torsionally flexible coupling fitted with compressible flexible elements. ...

Torque: 3,600 Nm - 644,400 Nm
Rotational speed: 650 rpm - 7,000 rpm

Torsional flexible coupling that is equipped with an elastic element working in compression. Suitable for motion reversals and multidirectional flexibility. (Area of) Applications Low speed shaft of machinery driven ...

Torque: 3,000 Nm - 20,023 Nm
Rotational speed: 1,900 rpm - 16,000 rpm

Torsionally flexible jaw coupling for electric motor driven high-speed shafts The FLEXOMAX GSN is a torsionally flexible coupling fitted with compressible flexible elements. ...

Torque: 15,000 Nm
Rotational speed: 19,000 rpm

Spider couplings, also known as jaw couplings, are torsionally flexible shaft couplings which enable the connection of shafts or flanges via a polyurethane drive ring. Parallel, ...

Torque: 10 Nm - 2,400 Nm
Rotational speed: 2,400 rpm - 8,000 rpm

These steel gear hub / nylon drive sleeve gear couplings are designed to release neighbouring shaft bearings from non-controlled additional bearing loads. Maximum shaft diameters of 100 mm can be accommodated ...

Torque: 24 Nm - 29,000 Nm
Rotational speed: 1,000 rpm - 4,500 rpm

ELPEX-B tyre couplings are highly flexible and free of torsional backlash. Because of their low torsional stiffness and damping capacity, these couplings are especially suitable for coupling ...

Torque: 3,000 Nm - 20,025 Nm
Rotational speed: 1,900 rpm - 16,000 rpm

... FLEXOMAX GSN is a torsionally flexible coupling fitted with compressible flexible elements. It compensates axial, angled and radial displacements between shafts and absorbs shocks and vibrations. This type of coupling’s ...

Torque: 12,500 Nm - 530,000 Nm
Rotational speed: 710 rpm - 2,750 rpm

... high-speed main/PTO systems driven by a Diesel engine or electric motor. In the low to middle torque range where the handling and installation of a complete element is practicable the couplings ...

Torque: 0.6 Nm - 200 Nm
Rotational speed: 6,000 rpm - 42,000 rpm

XHW series is disk type flexible coupling. High-torque specification with rated torque 1.5 times higher than conventional products. This is the most appropriate for a servomotor with instantaneous max. ...

Torque: 0 Nm - 21,000 Nm
Rotational speed: 600 rpm - 4,000 rpm

... FILL FLUID COUPLINGS: OPERATING CONDITIONS The TRANSFLUID constant fill fluid coupling is a hydrokinetic transmission. The impellers perform like a centrifugal pump and a hydraulic turbine. An input ...

Torque: 0 Nm - 10,000 Nm
Rotational speed: 1,000 rpm - 3,600 rpm

HYDRAULIC COUPLING FOR DIESEL AND ELECTRIC ENGINES – SPEED VARIATOR – STARTER The KPTB is a variable fill fluid coupling designed to be a start-up drive or variable ...
