Exposed linear encoders

Length: 50 m
Resolution: 244 nm - 250,000 nm

The LM13 is a contactless high-speed linear magnetic system designed for linear or rotary motion sensing in harsh environments. The system consists of a compact readhead and a separate selfadhesive ...

Length: 16.3 m
Resolution: 244 nm - 125,000 nm

LA11 is an absolute magnetic linear encoder system designed for motion control applications as a position and velocity control loop feedback element. The encoder system is highly reliable ...

Resolution: 0.2 µm

Incremental, digital interface, resolution 0.2 μm Repeat accuracy ±1 μm LED status display Reading distance ≤0.4 mm Robust metal housing

Resolution: 1 µm

Repeat accuracy max. ±1 μm LED status display Works with MB100/1 magnetic tape Works with MBR100 magnetic tape ring Reading distance ≤0.4 mm Signal period 1000 μm Output circuit sin/cos 1 VSS Robust metal housing

Resolution: 1 µm

High-resolution magnetic absolute sensor for use in dynamic processes Additional analog real-time signal output Sin/Cos 1 VSS for highly dynamic control (SSI/RS485) Repeat accuracy 2 μm System accuracy up to 10 μm SSI, RS485, DRIVE-CLiQ ...

Length: 40 mm - 420 mm
Resolution: 0.01 µm - 0.1 µm
Linear encoder speed: 0 mm/s - 400 mm/s

High-speed and high-resolution, while maintaining stable, ultraprecision measuring. Ideal for precision stages, semiconductor inspection/manufacturing systems, and ultraprecision processing machines. High-resolution scale with signal ...

Length: 90 mm - 3,740 mm
Resolution: 0.01 µm - 1 µm
Linear encoder speed: 200 m/min

Wide gap and clearance tolerance Individual non-contact component design 5 nm high-resolution Protocol : FANUC, Mitsubishi, YASKAWA, SIEMENS AG

Length: 200 mm - 30,000 mm
Resolution: 10 µm
Linear encoder speed: 300 m/min

Non-contact detection and a long measuring range Magnetic principle Excellent resistance to workshop conditions (PL20C equivalent to IP65). Max response speed: (varies with the read head and settings) Available in lengths (SL130) High ...

Resolution: 0.5 µm - 250 µm
Process temperature: -20 °C - 70 °C

New line of magnetic sensors MTS, with small overall dimensions. DPI resolution and inches reading now available. Many pole pitches available. Wide alignment tolerances and sensor/magnetic band distance up to 12 mm, ...

Resolution: 0 µm - 5 µm

The MTV Magnetic Reading system with sine-wave output from Givi Misure is engineered with a magnetic sensor body that is forged from die-cast metallic material. It is fitted with M4 holes or M3 screws for magnetic sensor mounting. The ...

Length: 0 mm - 30,000 mm
Resolution: 1 µm - 500 µm
Process temperature: -20 °C - 70 °C

Linear magnetic sensor, with direct reading of the absolute position. High performance, with a measuring length up to 30,000 mm. Extremely easy and fast mounting of the entire measuring system, with wide alignment tolerances ...

Resolution: 20 nm
Linear encoder speed: 0 m/s - 30 m/s
Output frequency: 0 MHz - 1 MHz

... connector The ID1102L incremental encoder kit consists of an encoder and a linear scale. The encoder is an integrated circuit in a PCB housing. It provides incremental ...

Resolution: 20 nm
Linear encoder speed: 0 m/s - 30 m/s
Output frequency: 0 MHz - 1 MHz

... connector The ID4501L incremental encoder kit consists of an encoder and a linear scale. The encoder is an integrated circuit in a PCB housing. It provides incremental ...

Resolution: 20 nm
Linear encoder speed: 0 m/s - 36 m/s
Output frequency: 0 MHz - 1.2 MHz

... The IT3402L incremental encoder kit consists of an encoder and a linear scale. The encoder is an integrated circuit in a PCB housing. It provides incremental A and B ...
