Acceleration range: -490 m/s² - 490 m/s²
Frequency: 0.5 Hz - 3,000 Hz
CE Modal array, ceramic shear ICP® accel, 100 mV/g, 0.5 to 3k Hz 10-32 side conn stud mount with IEEE 1451.4 TEDS 1.0 • Sensitivity: (±10%)100 mV/g (10.2 mV/(m/s²)) • Measurement Range: ±50 g pk (±490 m/s² pk) • ...
PCB Piezotronics GmbH
Acceleration range: -490 m/s² - 490 m/s²
Frequency: 0.5 Hz - 3,000 Hz
Modal array, ceramic shear ICP® accel, 100 mV/g, 0.5 to 3k Hz, 10-32 side conn., adhesive mount, TEDS version 1.0 • Sensitivity: (±10%)100 mV/g (10.2 mV/(m/s²)) • Measurement Range: ±50 g pk (±490 m/s² pk) • Broadband ...
PCB Piezotronics GmbH
Acceleration range: -49 m/s² - 49 m/s²
Frequency: 0.5 Hz - 3,000 Hz
Modal array, ceramic shear ICP® accel, 1000 mV/g, 0.5 to 3k Hz, 10-32 side conn., 5-40 stud mount, TEDS 1.0 • Sensitivity: (±10%)1000 mV/g (102 mV/(m/s²)) • Measurement Range: ±5 g pk (±49 m/s² pk) • Broadband Resolution: ...
PCB Piezotronics GmbH
Acceleration range: -490 m/s² - 490 m/s²
Frequency: 0.33 Hz - 12,000 Hz
Platinum Stock Products; General purpose, industrial, quartz shear ICP® accel., 100 mV/g, 0.3 to 12k Hz, top exit, 2-pin conn., frequency sweep ISO 17025 accredited calibration • Sensitivity: (±5%) 100 mV/g (10.2 mV/(m/s²)) • ...
PCB Piezotronics GmbH
Frequency: 0.25 Hz - 5,000 Hz
Low cost embeddable accelerometer, 2-wire ICP®, 1000 mV/g, TO8 housing, positive output, header pins • Sensitivity: (±20%)1000 mV/g (102 mV/(m/s²)) • Frequency Range: (±3dB)0.25 to 5k Hz (0.25 to ...
PCB Piezotronics GmbH
Frequency: 0.17 Hz - 10,000 Hz
... . Despite their economical name, low-cost accelerometers are ideal for applications where the sensors are permanently mounted to collect vibration data 24/7, monthly or even quarterly. Low-cost accelerometers ...
PCB Piezotronics GmbH
Frequency: 0.33 Hz - 10,000 Hz
Usually, acceleration sensors with ICP®/IEPE technology are used for vibration monitoring. Sensors for series use are particularly suitable if a large number of measuring points are to be monitored. The ...
PCB Piezotronics GmbH
Acceleration range: 490 m/s²
Frequency: 0.5 Hz - 10,000 Hz
... sensors of the M607 series also allow the cable to be aligned. This allows for a smaller design. - Industrial ICP®/IEPE accelerometer with integrated 3m cable - Measuring range ±50 ...
PCB Piezotronics GmbH
Frequency: 0.5 Hz - 8,000 Hz
... Temperature ICP®/ IEPE accelerometer, model HT602D01, is ideal for vibration measurements in higher temperature applications, including the paper, plastics and steel industries. These high temperature ...
PCB Piezotronics GmbH
Frequency: 0.27 Hz - 10,000 Hz
... Model 601A01 is suitable as a low-cost industrial ICP®/ IEPE accelerometer for a general purpose. It has a very good signal-to-noise ratio and a ceramic sensing element. The low-cost ICP®/ ...
PCB Piezotronics GmbH
Acceleration range: -50 m/s² - 50 m/s²
Frequency: 0.3 Hz - 32,000 Hz
Features: Innovative structure: wedge shaped self locking (more reliable and cost effective) Excellent frequency response for wide frequency range. Excellent signal-to-noise ratio for capturing subtle signals. Double shielding, signal ...
FATRI France
Acceleration range: -50 m/s² - 50 m/s²
Frequency: 0.1 Hz - 32,000 Hz
Miniaturised acceleration sensor Features: Innovative structure: wedge shaped self locking (more reliable) Excellent frequency response for wide frequency range. Excellent signal-to-noise ratio for capturing subtle ...
FATRI France
Acceleration range: -50 m/s² - 50 m/s²
Frequency: 0.3 Hz - 32,000 Hz
Side exit accelerometer Features: Innovative structure: wedge shaped self locking (more reliable) Excellent frequency response for wide frequency range. Excellent signal-to-noise ratio for capturing subtle signals. Double ...
FATRI France
Acceleration range: -50 m/s² - 50 m/s²
Frequency: 0.3 Hz - 18,000 Hz
Features: Innovative structure: wedge shaped self locking (more reliable) Excellent frequency response for wide frequency range. Excellent signal-to-noise ratio for capturing subtle signals. Double shielding, signal and power supply ...
FATRI France
Frequency: 0.7 Hz - 10,000 Hz
- Built-in IEPE circuit, isolation output, constant current source power supply. - Laser seal welded. - Using military connector, can be used for on-line monitoring in harsh industrial sites Parameters - Index Basic parameters Sensitivity ...
Acceleration range: 0 m/s² - 60 m/s²
Frequency: 0.1 Hz - 4,000 Hz
High Sensitivity Accelerometers Properties • Suited for seismic measurement and building vibration, particularly at low frequencies • Extremely sensitive piezo system provides excellent resolution and lowest noise • ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 6,000 m/s²
Frequency: 0.15 Hz - 26,000 Hz
Triaxial Accelerometers Properties • Small dimensions • Excellent phase response • High resolution • Low temperature coefficient • Includes electronic data sheet (TEDS) • Suitable for modal and structural analysis Sensitivity ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 80,000 m/s²
Frequency: 0.3 Hz - 35,000 Hz
Miniature Accelerometers Properties • For light test objects • With IEPE voltage output • With sensitivities 10 mV/g and 100 mV/g • Good resolution, also at low frequencies • High resonant frequencies • KS94C10/100 ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 6,000 m/s²
Frequency: 0.3 Hz - 37,000 Hz
Miniature Accelerometers Properties • For light test objects • KS91C in subminiature design • KS91C with IEPE voltage output • Wide dynamic range • Low temperature coefficient • High resonant frequency • Replaceable ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 5,000 m/s²
Frequency: 0.2 Hz - 18,000 Hz
Miniature Accelerometers Properties • IEPE precision accelerometers with shear ceramics • Well suited for modal and structural analysis • Easy mounting by cubic case with M3 thread • Versions ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 5,000 m/s²
Frequency: 0.2 Hz - 18,000 Hz
Miniature Accelerometers Properties • IEPE precision accelerometers with shear ceramics • Well suited for modal and structural analysis • Easy mounting by cubic case with M3 thread • Versions ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 5,000 m/s²
Frequency: 0.2 Hz - 16,000 Hz
Miniature Accelerometers Properties • IEPE precision accelerometers with shear ceramics • Well suited for modal and structural analysis • Clip mounting in 3 directions • TEDS Sensitivity Type: ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 600 m/s²
Frequency: 0.15 Hz - 11,000 Hz
Miniature Accelerometers Properties • IEPE precision accelerometers with shear ceramics • Well suited for modal and structural analysis • Clip mounting in 3 directions • TEDS Sensitivity Type: ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 6 m/s²
Frequency: 0.05 Hz - 260 Hz
High Sensitivity Accelerometers Properties • Suited for seismic measurement and building vibration, particularly at low frequencies • Extremely sensitive piezo system provides excellent resolution and lowest noise • ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Acceleration range: 0 m/s² - 5,000 m/s²
Frequency: 0.2 Hz - 18,000 Hz
Triaxial Accelerometers Properties • Low profile • Excellent amplitude response • High resolution • Low temperature coefficient • Includes electronic data sheet (TEDS) • Suitable for modal and structural analysis • ...
Metra Mess- und Frequenztechnik in Radebeul e.K.
Frequency: 0.1 Hz - 100 Hz
... adapter SA 38 (option). Features: •Meets ISO 8041 and ISO 2631 •IEPE / ICP powering •Low price •Dedicated to SVAN 958 and SVAN 958A SV 38 Whole-body Triaxial Accelerometer Specification ...
