Large part boring mills

X travel: 3,200 mm - 8,500 mm
Y travel: 2,700, 3,200, 3,600 mm
Z travel: 1,000, 1,250 mm

Gantry framework whole gantry milling and boring machine inherited the characteristics of the traditional gantry machine with strong infrastructure rigidity, symmetrical structure, strong stability, on ...

Y travel: 2,500 mm - 12,000 mm
Z travel: 1,250 mm - 2,000 mm
W travel (spindle): 1,000 mm - 1,800 mm

Medium and large size horizontal milling and boring machines, with movable column and preloaded hydrostatic bearing, suitable for machining large size components Their ...

X travel: 1,800 mm
Y travel: 1,600 mm
Z travel: 1,400 mm

... ● The main shaft consists of one facing spindle, one milling spindle , and one boring spindle; ● Complete a variety of processes in one clamping, suitable for large parts ...

X travel: 1,600 mm
Y travel: 1,200 mm
Z travel: 1,000 mm

... torque was produced at the spindle to handle a large variety of materials. The overall machine structure was design to withstand the stress of heavy parts in the energy industry such as fracking components, ...

The horizontal plate boring machine with extending ram and main spindle marked WRD 13 is based on the original generation of WHN 13 CNC horizontal milling and boring machines produced ...

X travel: 2,000, 3,000, 4,000, 7,000, 1,600 mm
Y travel: 1,500, 2,000, 2,300, 4,000 mm
Z travel: 1,300, 2,500, 1,600, 1,500, 1,200 mm

Multi-functional and highly précisé and efficient machine with long-nose spindle and wide table invented for the machining of large parts
