Linear axis

Stroke : 50 mm - 850 mm
Speed: 180 mm/s - 650 mm/s
Force: 43 N - 400 N

Electric linear guide with high rigidity and absolute encoder for AC and DC power supply EZS Series Features: Battery-free absolute sensor No external sensors required Low heat generation High stiffness EtherCAT, ...

Stroke : 0 mm - 5,500 mm
Speed: 0 m/s - 8 m/s
Force: 110 kN

... available with a toothed belt or ballscrew for driving the carriage and a guide system with rollers or ball bearings The axis sizes are optimally matched to customer requirements The motor can be changed in ...

Stroke : 0 mm - 1,500 mm

Standardised linear tables for a wide range of linear movements - Cartesian Linear Axes Lexium TAS linear table Applications requiring feed movement without mechanical ...

Stroke : 800 mm
Speed: 16.76 mm/s - 166.62 mm/s
Force: 250 N - 2,000 N

Thomson compact linear systems address the need for thrust and bearing support in a single, small-scale unit for space-conscious applications. Whether you opt for one of our three standard architectures or work with our ...

Stroke : 6,000, 3,000, 4,000 mm
Speed: 1, 1.3, 1.6 m/s
Force: 200 N - 5,000 N

MG-K (Movoparts): Slide Guided, Screw Driven Linear Units Thomson's Movopart® MG-K rodless actuator slides provide guided linear motion through a ball ...

Stroke : 5,000, 12,000, 7,000 mm
Speed: 5 m/s
Force: 200 N - 3,005 N

... Movoparts): Slide Guided, Belt Driven Linear Units Thomson's Movopart® MG-B rodless actuator, slide guided versions are designed to move light loads at medium application ...

Stroke : 50 mm - 500 mm
Speed: 800 mm/s

Motor output (W): 50 Maximum payload (kg): 5 – 10 (horizontal), 1.5 – 3 (vertical) Positioning repeatability (mm): ±0.02

Stroke : 50 mm - 700 mm
Speed: 800 mm/s

Motor output (W): 50 Maximum payload (kg) (Note 1): 12 – 30 (horizontal), 4 – 8 (vertical) Positioning repeatability (mm): ±0.02

Stroke : 50 mm - 150 mm
Speed: 600 mm/s

Motor output (W): 50 Maximum payload (kg): 4 (horizontal), 1.9 (vertical) Positioning repeatability (mm): ±0.02

Stroke : 50 mm - 6,000 mm
Speed: 2.5, 5 m/s

Series 5ES...BS axes are mechanical linear actuators in which the rotary movement generated by a motor is converted into a linear movement by means of a recirculating ball screw. Series 5E is designed ...

Stroke : 100 mm - 3,000 mm
Speed: 1,000 m/s
Force: 10,900 N

... repetitive tasks, usually done manually, are time consuming and with low added value for the operators. By adding a linear module as a dynamic base for the robot, it is possible to extend the handling ...

Stroke : 15 mm - 450 mm
Force: 90 N - 260 N

The LEPK linear units are designed for horizontal or vertical mounting. They are driven by an ISO 6432 pneumatic cylinder that can be easily removed when it needs to be replaced. The ...

Stroke : 1 m - 21 m
Speed: 2 m/s

Modular platform design ABB’s Medium Track Motion (MTM)’s design is smart and compact with a symmetrical profile. Maximum integration ensures the protection of components in a small footprint. The IRBT 2005 consists of a standard 1 ...

Stroke : 1.9 m - 19.9 m
Speed: 2 m/s

It is adapted for the large robot families IRB 4X00, IRB 66XX, IRB 6700 and IRB 7600. The track motion has a unique performance. This is possible thanks to a build in motion planning that considers all dynamic forces when planning combined ...

Stroke : 1.7 m - 19.7 m
Speed: 1.6 m/s

It is adapted for the large robot families IRB 4X00, IRB 66XX, IRB 6700 and IRB 7600. The track motion has a unique performance. This is possible thanks to a build in motion planning that considers all dynamic forces when planning combined ...

Stroke : 5,500, 3,000 mm
Speed: 5, 3 m/s
Force: 6,000, 1,852, 1,323, 450 N

... combined into double axes and multi-axis systems depending on requirements. HIWIN linear axes with ballscrews are available for applications that require high feed forces and precision. HIWIN linear ...

Stroke : 5,500, 3,000 mm
Speed: 5, 3 m/s
Force: 4,000, 1,240, 880, 300 N

... combined into double axes and multi-axis systems depending on requirements. HIWIN linear axes with ballscrews are available for applications that require high feed forces and precision. HIWIN linear ...

Stroke : 5,500 mm
Speed: 5 m/s
Force: 813, 3,000, 1,300, 4,500 N

... combined into double axes and multi-axis systems depending on requirements. HIWIN linear axes with ballscrews are available for applications that require high feed forces and precision. HIWIN linear ...

... expanding its range of single-tube linear actuators for easy manual adjustment with the addition of the RK LightUnit-G and RK LightUnit-G telescope slide guides. The special characteristics of the new ...

Stroke : 0 mm - 5,677 mm
Speed: 0 m/s - 10 m/s
Force: 4,367 N

... conditions, we are supplementing our series of toothed belt driven linear axes of the type RK MonoLine with a completely corrosion-protected variant in the common size 80. The compact linear units ...

Stroke : 10 mm - 2,769 mm
Speed: 2 mm/min - 1,020 mm/min
Force: 500 N - 2,100 N

E-II-stainless: 100% corrosion-resistant single-tube linear units The E-II single-tube linear unit is an all-rounder for format adjustment. The E-II stainless steel ...

Stroke : 50 mm - 300 mm
Speed: 300 mm/s
Force: 3 kgf

... ? 2.How long stroke do need the linear be? 3.How is the load and speed need? 4.Do need motor and accessory together? If need OEM or other special requirement, please tell us. Ball Screw Module, Belt Driven Linear ...

Stroke : 50 mm - 1,000 mm
Speed: 40 mm/s - 250 mm/s
Force: 10 kgf - 25 kgf

Technical Feature FSK40 linear guide is semi-sealer structure, body width 40mm, high stability,compact structure,versatility feature, suitable for normal working environment, it is convenient to use single axis or multi-axis ...

Stroke : 50 mm - 1,200 mm
Speed: 60 mm/s - 220 mm/s
Force: 20 kgf - 40 kgf

... Value-Added Services Dust Water Proof Enclosed Ball Screw Linear Module Technical Feature FSL80 linear guide, fully sealed structure, body width 80mm, it is designed for dustproof ...

LINEAR UNIT LEZ 4G WITH TOOTHED BELT DRIVE The completely enclosed drive unit has an internal roller guide with lifetime lubrication. It is fitted with a stainless steel cover as standard, which prevents ...

ILE 20/20 HEAVY-DUTY LINEAR UNITS FOR INCREASED LOADS AND FEED FORCES! The iLE 20/20 is based on sophisticated linear technology that has been continuously developed based on many ...

Stroke : 150 mm - 280 mm
Force: 170 N - 250 N

... available! Maximum length of up to 3490 mm on request. OPTIONS Black anodized aluminium profile Electromagnetic brake Steel slides LS2 (Part no. 223007) Limit switch attachment kit (see accessories) AVAILABLE ...

Stroke : 25 mm - 1,740 mm
Speed: 0 m/s - 1.2 m/s

Spindle drives Maximum load Spindle drives combine large strokes with high precision at high strain. strokes up to 1700 mm load up to 5000 N speed up to 1,2 m/s up to +/- 0.003 mm repeat accuracy

Toothed belt drives Maximum distance Toothed belt drives are ideal for handling light-weight to heavy components across large distances. strokes up to 5500 mm load up to 800 N speed up to 5 m/s up to +/- 0,04 mm repeat accuracy

Stroke : 0 mm - 3,700 mm
Speed: 0 m/s - 5 m/s

Direct drives - Maximum dynamics! Direct drives are suitable for quick handling at the highest precision. Features - strokes up to 3700 mm - load up to 500 N - speed up to 5 m/s - accelerations up to ...

Stroke : 0 mm - 400 mm
Speed: 1, 0.2 m/s

... absorbers Exit intermediate position Manipulator made with your components = competitiveness These linear units make it possible to carry out any translation requiring precision ...

Stroke : 25, 50 mm
Force: 30 N - 100 N

LINEAR RAIL SLIDES Precise profile guide The linear guide with ball bearing circulation and scrapers provides high precision and rigidity Standardised adapter plate Reduce your ...

Stroke : 50, 100 mm
Force: 265, 220 N

LINEAR RAIL SLIDES Precise profile guide The linear guide with ball bearing circulation and scrapers provides high precision and rigidity Dampened end position By using PowerStop ...

Stroke : 200, 50, 100 mm
Force: 265, 680, 220, 750 N

LINEAR RAIL SLIDES Precise double rail profile guide The linear guide with ball bearing circulation and scrapers provides high precision and rigidity Dampened end position By using ...

Built-in self-lubricating series Belt series & screw series Built in linear rail design, Straightness and Flatness are highly improved. Wide ranges of structure,bespoke installation. Equipped with customized high ...

KERK® RGS/RSW Linear Guide series are built to provide solid and steady platform for a wide range of liner motion applications. It is crafted from high quality extruded aluminum and Kerkite® composite polymer with Kerkote® ...

Stroke : 5 mm - 100 mm

Stroke : 25 mm - 100 mm

Stroke : 500 mm - 3,000 mm
Speed: 2 m/s
Force: 80 N - 200 N

BEMA Series motorized belt drive linear actuators operate at speeds up to 2 m/sec and do not require lubrication or maintenance under normal operating conditions. These actuators are ideally suited for high speed automation ...

Stroke : 2,400 mm
Speed: 6 m/s
Force: 234 N - 1,409 N

... and the use of high-performance, iron-core linear motors. Thanks to the stiff and low-vibration design, high positioning accuracies can be achieved – even with very high dynamics. The design – with two linear ...

Stroke : 2,000 mm
Speed: 6 m/s
Force: 150 N - 900 N

... design, the linear motor systems are not only cost-effective, but also well suited for very harsh environments. They are also ideal for setting up cross-table and gantry systems (more information can be found under the ...

Stroke : 2,200 mm
Speed: 6, 8 m/s
Force: 150 N - 1,408 N

... With its ironless motor winding, the LMS 2.IL linear motor system achieves a synchronisation that is a whole power of ten better than that of the LMS 2 series. The LMS 2.IL series of standard KML linear ...

Stroke : 1 mm - 6,000 mm
Speed: 1 m/s
Force: 100 N - 10,000 N

Rack guides are used when long work tracks have to be made. The rack guides are also employed when all the space available must be used, and when the carriage stands still and the guide moves. Standard rack guides have racks with straight ...

Stroke : 2,000 mm
Speed: 1 m/s
Force: 100 N - 1,000 N

Screw guides are used when a positioning precision of less than 0,1 mm (worm drive screw) is required, when using very low speeds, and when the unit has to be of compact size. In the screw guides the fitting of the motor directly coupled ...

Stroke : 1 mm - 6,000 mm
Speed: 3 m/s
Force: 10 N - 1,000 N

The movement systems you can see in this page show some of the many possible solutions for 3-axis (X-Y -Z) movement we have in our archive. In this case too, the type of application and the working conditions requested ...

Stroke : 50 mm
Speed: 0.03 m/s
Force: 240 N - 13,500 N

The TBS is a high precision linear axis with a 1 Degree Of Freedom. This is a mechanical bearing based indirect drive linear axis providing outstanding performance in ...

Stroke : 100 mm - 7,000 mm
Speed: 0 m/s - 5 m/s
Force: 428 N - 47,160 N

... production of linear modules, linear axes and linear actuators for automation. The linear systems are entirely manufactured in-house and include various drive types: ...
