Radial rotary unions

Rotational speed: 0 rpm - 4,000 rpm
Pressure: 0 psi - 1,000 psi
Nominal size: 1.125 in - 2.25 in

Rotary Systems’ Series 008 rotary unions feature mechanical face seal technology for low torque, high speed and moderate pressure applications. Found in air or hydraulic clutches, these ...

Rotational speed: 0 rpm - 1,500 rpm
Pressure: 0 bar - 100 bar
Nominal size: 0.25 in - 5 in

High pressure hose connection with jacks. Hydraulic control. Technical Data: Surface treatment: Chemical Nickel Implantation: Angle elbow Temperature working: -20°C à 200°C Connection: Thread BSP *for any other type of connection, ...

Rotational speed: 0 rpm - 3,500 rpm
Pressure: 150, 1,000 psi
Nominal size: 0.125 in

Monoflow design Self-supported rotating union Radial housing connection Balanced mechanical seals Seal combinations: Carbon Graphite/Hardened Tool Steel or Carbon ...

Rotational speed: 15,000 rpm
Pressure: 0 bar - 350 bar
Nominal size: 15 mm - 360 mm

For high pressures and speeds The tried-and-tested ROTOSTAT E sealing system uses a hydrostatically controlled radial gap seal, ensuring reliable operation even under the most demanding operating conditions. Extremely ...

Rotational speed: 0 rpm - 150 rpm
Pressure: 0 bar - 150 bar
Nominal size: 0.25 in - 4 in

... ) DN : 1/4” to 4” (axial output) Pressure : Up to 150 bar (2175 Psi) Temperature : Up to 60°C (140°F) Sealing system: Radial seal Other configurations on request Full data sheets also available • Male/female ...

Rotational speed: 1,000 rpm
Pressure: 80 bar - 1,160 bar

High quality rotary union especially suitable for medium speed with coolant. Labyrinth seal and drain holes protect bearings from leakage. Silicon carbide seal faces resist wear and thermal shock Precision ...

Rotational speed: 0 rad.min-1 - 3,500 rad.min-1
Pressure: 10 bar
Nominal size: 57 mm

... installed): ØO = 57 mm x L = 66,2 mm Connecting dimensions: Rotor (axial): 1x G 1/2" A RH Stator (radial): 1x 1/2" NPT Pressure / Flow Rate air: 10 bar vacuum: 6,7 kPa ...

Pressure: 20 bar

Quadruple bearing system Long service life Corrosion resistant Application: Thrust and radial forces, high pressure, industrial or food service applications

Rotational speed: 16,000 rad.min-1 - 75,000 rad.min-1
Pressure: 50 bar - 80 bar

... up to 360° to make it easier to install. All GD rotary unions are available with radial and axial connections. Maintenance cycles can be calculated, which ensures optimal availability. GD ...

Rotational speed: 0 rpm - 100 rpm
Pressure: 0 bar - 10 bar
Nominal size: 75, 65 mm

... 1" DN25 3/4" DN20 Connection Type FL, BSPP, BSPT, NPT, Metric Dual Flow Stainless Steel Shaft/Rotor Nodular casting body Radial housing connection Silicon Carbide /Silicon Carbide

Rotational speed: 0 rpm - 250 rpm
Pressure: 0 bar - 450 bar
Nominal size: 6 mm - 25 mm

... HYDRAULIC, WATER GASES, ALL KINDS OF LIQUIDS 1/8” (DN06) - 1” (DN25) - Self supported rotating joint - Radial housing connections as standard - Axial / radial shaft outlets - Steel, ...

Rotational speed: 750 rpm - 15,000 rpm
Pressure: 0 bar - 100 bar

ROTOFLUX rotary joints The ROTOFLUX type rotary joints, marketed by SENGA, are used in a wide range of applications: with water, steam, hot oil, compressed air, vacuum, hydraulic oil, ...

Rotational speed: 65 rpm - 100 rpm
Pressure: 5,000 psi

• High rotation per minute • Low starting torque • Internal oil bearings for increased lifetime • Manifold mounting adaptors available to reduce fixture plumbing

Rotational speed: 100 rpm
Pressure: 50 bar
Nominal size: 135 mm

... speed: 0~60RPM Working temperature: -10~90 centigrade Slip ring is designed to use to transmit power, signal or data, pneumatically or hydraulically from a stationary to a rotating platform. It ...
