Rectifier diode rectifier bridges

Reverse voltage: 100 V - 1,000 V

... 120mm2 of board space needed for industry standard 1.0 Amp surface mount bridge rectifier. • 50% higher density (Amps/mm2) than the industry standard 1.0 Amp surface mount bridge rectifier. • ...

Reverse voltage: 800, 600 V

Thanks to highly sensitive triggering levels, the 4PT series is suitable for all applications where the available gate current is limited, such as motor control for hand tools, kitchen aids, capacitive ...

Reverse voltage: 600 V - 1,200 V

Typical IR less than 2.0 µA High surge capability Low thermal resistance Isolation voltage up to 2500V UL approved file E320098 Compliant to RoHS Applications Industrial automation Field supply for DC motor

Reverse voltage: 1,200 V - 1,600 V

Typical IR less than 1.0 µA Solder dip 260°C, 40s High surge capability Low thermal resistance UL approved file E320098 Compliant to RoHS Applications Home appliances Office equipment Industrial automation

Reverse voltage: 800 V - 1,200 V

Typical IR less than 1.0 µA Solder dip 260°C, 40s High surge capability Low thermal resistance Glass passivated chips UL approved file E320098 Compliant to RoHS Applications Home appliances Office equipment Industrial automation

Reverse voltage: 1,600 V

Typical IR less than 1.0 µA Solder dip 260°C, 40s High surge capability Low thermal resistance Glass passivated chips UL approved file E320098 Compliant to RoHS Applications Home appliances Office equipment Industrial automation

Reverse voltage: 800 V - 1,800 V

Typical IR less than 2.0 µA High surge capability Isolation voltage up to 2500V Low thermal resistance UL approved file E320098 Compliant to RoHS Applications Field supply for DC motor Industrial automation

Reverse voltage: 1,200 V - 1,600 V

2500 VRMS isolating voltage High surge capability Low thermal resistance Simple mounting UL approved file E320098 Designed and qualified for industrial level Compliant to RoHS Applications Inverter for AC or DC motor control Current ...

Reverse voltage: 36 kV

INTRODUCE: Rongtech high voltage silicon rectifier assembly is made of high quality silicon wafer chip and high reliability epoxy resin sealing structure, and through professional testing equipment inspection qualified ...

Reverse voltage: 36 kV

INTRODUCE: Rongtech high voltage silicon rectifier assembly is made of high quality silicon wafer chip and high reliability epoxy resin sealing structure, and through professional testing equipment inspection qualified ...

• Chips are electrically insulated form bottom plate • Package in complance with international standard.Pressure type, excellent temperature characteristics and power cycling capability • 350A below modules are forced air cooling;400A ...
