Robotic position sensors

Power consumption: 1.5 W
Supply voltage: 4.5 V - 30 V
Ambient temperature: -40 °C - 105 °C

... and enable use in dynamic applications. Industrial and medical applications e.g., motor feedback, handling automation and robotics Integration into small installation space possible Absolute resolution up to 20 Bit Repeatability ...

... mechanical position sensors detect one or two positions within a single, compact electromechanical component. Two independent commutations can sense two previously ...

Measuring range: 50 mm - 1,250 mm

... wire position transducer is designed for industrial applications. The instrument is compact in size and has short assembly time. The device is also easy to customize and hence offers economical solution ...

Measuring range: 3,000 mm - 5,000 mm

Ranges from 3125 to 6000 mm Linearity max. ±0.02 % Output analog 0...10 V, 4...20 mA, Potentiometer Output digital TTL, HTL, SSI, Profibus, CANopen, DeviceNet, Ethercat, Profinet Protection class IP65 (optional IP67)

Measuring range: 6 m - 42.5 m

The SX135 Long Range Draw Wire Sensors are manufactured by WayCon Company. The sensors are made of stainless steel. They are applied in humid and moderate corrosive environmental conditions. These ...

The 9600 Series Linear Position Sensor, is designed for a variety of space limited feedback applications that require high accuracy. It is ideally suited for Industrial, vehicular, appliance, machine ...

Measuring range: 50 mm - 950 mm
Linearity: 0.1 %

The linear motion potentiometers series PNS have a 31 mm square section housing and 6 mm diameter shaft. Their measuring strokes range from 50 to 950 mm, and their standard resistive value is 5 KOhm. The conductive plastic resistive ...

Measuring range: 25 mm - 150 mm
Linearity: 0.1 % - 0.2 %

Thanks to their small size – 21 mm square section case – the linear potentiometers seris PT can be profitably employed for those applications where limited dimensions are a critical factor. The series strokes range from 25 to 150 mm. ...

Measuring range: 50 mm - 950 mm
Linearity: 0.1 % - 0.1 %
Supply voltage: 18 V - 30 V

The transducers series PNS-V, PN2S-V and PN231-V provide the 0÷10Vdc analogue output signal proportional to the position reached by the rod. The active electronics makes it easy to interface the transducers to external ...

Measuring range: 500 mm
Linearity: 0.15 %
Supply voltage: 32 V

Potentiometric linear displacement sensors enable motion control and position measurement. The sensor provides an ohmic value proportional to the movement of the mobile over a maximum ...

Measuring range: 0 mm - 1,250 mm
Linearity: 0.1 % - 0.5 %
Ambient temperature: -20 °C - 80 °C

... displacement sensors are suitable for motion control and position measurement. This potentiometer is coupled to the drum, so the mechanical movement is converted into a resistance value according to ...

Measuring range: 0 mm - 1,250 mm
Linearity: 0.1 %
Supply voltage: 11 V - 27 V

Analog linear draw wire sensors are suitable for motion control and position measurement. The drum being coupled to a potentiometer which converts the linear mechanical movement into a resistive value ...

Measuring range: 50 cm
Linearity: 0.3 %
Supply voltage: 5 V - 30 V

XL50S Series Draw wire sensor The draw wire sensor is widely considered on construction, forklift, automation and food packaging machines. - Draw-wire position sensor ...

Measuring range: 600 mm - 1,500 mm
Supply voltage: 24, 5 V
Ambient temperature: -30 °C - 85 °C

XL60 Series Draw Wire Sensor - Economical version Draw Wire Sensor - Availabe for multi-turn wirewound potentiometer incorporated (W type) - Available for multi-turn Hall effect contactless ...

Measuring range: 0 cm - 0 cm
Linearity: 0.5 %
Supply voltage: 24 V

XL80 Series Draw-wire Position Sensor - Incorporate multi-turn contact/contactless potentiometer - Long ranges - Measurement ranges 3000mm - Output signal: 5K,10K，0~5V, 0~10V, 4~20mA General Mechanical ...

Supply voltage: 5 V - 32 V
Ambient temperature: -40 °C - 85 °C

Contactless / Full redundant double die hall sensor 0 – 360° programmable (0.1° resolution ) 6 way, Delphi Packard Metri Pack 150 10 Million lifetime cycles Outputs: Analog+IVS type: Analog + HighSide or LowSide ...

Measuring range: 0 mm - 100 mm
Linearity: 0.1 %
Ambient temperature: -30 °C - 100 °C

• Sensor connection: 4-pin M12x1 plug connector Displacement sensor with resistance and collector path of conductive plastic on a glassfibre reinforced substrate with internal return spring for direct ...

Measuring range: 500 µm - 10,000 µm
Measuring rate: 100 Hz - 35,000 Hz
Supply voltage: 10 V - 36 V

Eddy current sensors detect the distance or the change to metal objects without contact, dynamically and extremely accurately. The TX electronics which are specially adapted to the respective sensor calculate ...

Measuring range: 50 m

... accuracy applications by determining the position (x, y, z) and angular orientation (pitch, yaw, roll) of a tracked point in real-time revealing the real-time true position and orientation of a moving ...
