Screw cylinders

Stroke : 30 mm - 1,500 mm
Force: 600 N - 1,700 N
Speed: 0.1 m/s - 1.3 m/s

... powerful electric cylinder ESBF shines wherever heavy-duty, reliable positioning is required together with precision and dynamic response. • Available with ball screw drive (size 32 ...

Stroke : 25 mm - 500 mm
Force: 75 N - 900 N
Speed: 0.1 m/s - 0.2 m/s

... movements in every installation position and especially for vertical Z movements • Precise positioning due to smoothly running ball screw drive • Compact dimensions • Safe movement due to flexible ...

Stroke : 30 mm - 1,000 mm
Bore: 32 mm
Force: 1,000 N

... the ELEKTRO ROUND DC cylinder, the forward movement of the piston rod is obtained via an acme screw and a self-lubricating technopolymer nut. This piston has a guide ring that is calibrated to minimize ...

Force: 300 N - 5,200 N
Speed: 500, 200 mm/s
Ambient temperature: -10 °C - 50 °C

... geared version. The new Elektro SSC can be made with either a hardened and tempered steel screw and a ball recirculating screw nut or a stainless steel screw and technopolymer lead ...

Stroke : 0 mm - 500 mm
Force: 3,000, 5,200, 3,160 N
Speed: 200, 500, 50 mm/s

... interface suitable foi ISO 15552 cylinder accessories, is provided to be fixed to the cylinder from the rear side. The cylinder can be supplied with a STEPPING or a BRUSHLESS motor, ...

Stroke : 100 mm - 1,500 mm
Force: 6,600 N - 11,300 N
Torque: 2.5 Nm - 24.9 Nm

The Series 6E cylinders are mechanical linear actuators with rod, in which the rotary movement, generated by a motor, is converted into a linear movement by means of a recirculating ball screw. Available ...

Stroke : 100 mm - 500 mm
Rotation angle: 0.4 °
Ambient temperature: 0 °C - 50 °C

... lines, packaging systems or for material handling. Construction - electromechanical cylinder with recirculating ball screw Design - profile with thread rolling ...

Stroke : 50 mm - 300 mm
Force: 40 N - 500 N
Speed: 150, 300, 600 mm/s

Electric cylinders with absolute encoder for AC and DC power supply EAC series Features: Battery-free absolute sensor No external sensors required Low heat generation EtherCAT, EtherNet/IP, Profinet, Modbus ...

Stroke : 25 mm - 1,000 mm
Force: 0 N - 16,000 N
Speed: 0 mm/s - 7.6 mm/s

MA3 electric actuator is the most powerful that affords a maximum 16,000N force (push/pull). It was specifically designed for heavy-duty applications and harsh working environments that require durability. Examples of applications suitable ...

Stroke : 1,500, 1,000, 2,000, 500 mm
Force: 6,000 kgf - 32,000 kgf
Torque: 124 Nm - 1,109 Nm

The smaller, lighter U Series Power Cylinder with more than 6 tons rated thrust. Power cylinder that succeeds in providing a smaller, lighter unit with better cost performance while maintaining the same ...

Stroke : 200 mm - 2,000 mm
Force: 49 kN - 294 kN
Motor power: 0 kW - 11 kW

Worm series is the perfect power cylinder to replace hydraulic cylinders. Worm Series LPWB provides large thrust by using a high precision worm gear and a highly efficient ball screw ...

Stroke : 200 mm - 2,000 mm
Force: 2,450 N - 313,000 N
Torque: 1.33 Nm - 666 Nm

... low-noise operation; High-efficiency ball screw developed for cylinders; Safety mechanism that protects other devices; Extensive options. Can also be used outdoors. (Motor protection ...

Stroke : 100 mm - 1,500 mm
Force: 2.5 kN - 30.4 kN
Torque: 2.4 Nm - 92.2 Nm

Electric Cylinder based on ISO15552 Maintenance-free Guiding System - Sliding

Stroke : 300 mm - 3,100 mm
Force: 70, 160, 110 kN
Motor power: 30 kW

... motor and spindle inside the cylinder. This spring carries a large part of the constant load. The motor and spindle are primarily used to accelerate and decelerate the moving load. This increases the service life of the ...

Force: 5 kN - 350 kN
Torque: 1.65 Nm - 417.7 Nm
Speed: 0.5 m/min - 5.4 m/min

FREN Electric cylinders are an advancement of our standard program. By thought construction is an electrical cylinder in the situation also components out to be taken up. The lift link inside electrical ...

Force: 0 kN - 18 kN

... Optional IP66 and IP68 class possible - Standard ball screw drive

Stroke : 100 mm - 1,000 mm
Force: 15,000, 10,000 N
Speed: 0 mm/s - 1,250 mm/s

New electric cylinder for heavy-duty applications RK Rose+Krieger has expanded its range of electric cylinders with the introduction of an additional electromechanical heavy-duty cylinder: ...

Stroke : 0 mm - 2,000 mm
Force: 0 N - 25,000 N
Speed: 933, 126 mm/s

SLZ 90 Electric cylinder The powerful linear cylinder for precise positioning tasks up to 25000 N

Stroke : 10 mm - 25 mm
Rod diameter: 5 mm - 32 mm
Force: 2.7 kN - 109 kN

• screw type cartridge • direct supply in the block • spring return • domed or tapped end with flats • supplied with O-ring and anti-extrusion ring • steel body with anti-corrosion treatment • ...

Stroke : 20 mm - 50 mm
Rod diameter: 10 mm - 32 mm
Force: 10.8 kN - 109 kN

• screw type cartridge • direct supply in the block • spring return • domed or tapped end with flats • supplied with O-ring and anti-extrusion ring • steel body with anti-corrosion treatment • ...

Stroke : 16, 20, 25, 32 mm
Rod diameter: 10, 12, 16, 20 mm
Force: 7 kN - 28 kN

• screw type cartridge • direct supply in the block • available with Viton™ seal (100°C < T° < 150 °C) • supplied with O-ring and anti-extrusion ring • steel body with anti-corrosion treatment • treated steel rod • ...

Stroke : 40 mm - 20,000 mm
Force: 0.3 kN - 60 kN
Torque: 0.14 Nm - 265.39 Nm

... Series Servo Electric Cylinder with advanced servo cylinder structure design and imported parts assembly, ensure that Lim-Tec servo electric cylinder in the domestic leading linear motion.Rolled ...

Force: 2 kN - 20 kN

... IP55. ZBT parallel synchronous belt ball screw electric cylinder Thrust range： 0.2 to 2 tons Max speed：200mm/s Max stroke：2m Accessories: brake motor, encoder, limit switch, dust ...

Stroke : 500 mm - 3,000 mm
Force: 600 N - 150,000 N
Torque: 0.53 Nm - 2,331 Nm

LIM-TEC IMB Series Servo Electric Cylinder with advanced servo cylinder structure design and imported parts assembly, ensure that Lim-Tec servo electric cylinder in the domestic leading ...

Force: 450 N - 2,500 N
Motor power: 90, 60 W
Speed: 5 mm/s - 110 mm/s

Permanent magnet motor CE Worm gearbox Acme lead screw Chrome plated steel push rod Permanent grease lubrication IP 65, tested according to rule CEI EN 60529 Working temperature range -10°C +60°C Intermittent duty S3 ...

Force: 2,400 N - 4,200 N
Speed: 0.6 mm/s - 30 mm/s
Ambient temperature: -10 °C - 60 °C

Permanent magnet motor CE Worm gearbox Acme lead screw Chrome plated steel push rod Permanent grease lubrication IP 65 Working temperature range -10°C +60°C Intermittent duty S3 30% (5 min) a 30°C Limit switches, potentiometer ...

Force: 2,600 N - 6,000 N
Motor power: 90 W
Speed: 2.5 mm/s - 35 mm/s

Permanent magnet motor CE Worm gearbox Acme lead screw Chrome plated steel push rod Permanent grease lubrication IP 65 Working temperature range -10°C +60°C Intermittent duty S3 30% (5 min) 30°C* Limit switches, potentiometer ...

Stroke : 600 mm
Force: 5,000, 8,600, 900 N
Max acceleration: 12 m/s²

... in ISO1552 pneumatic Cylinder dimensions as standard, and many different stepper or Servo motors can be connected according to the desired speed and force. Fasteners used in pneumatic cylinders can ...

Stroke : 10 mm - 800 mm
Rod diameter: 16 mm
Force: 1.02, 0.68, 2.03, 1.36, 2.71 kN

Electric Cylinder DGRST65's power needs the help of ball screw for linear motion, with high efficiency up to 85%. The rod(shaft end) moves back and forth for positioning or lifting. It's ...

Stroke : 10 mm - 1,000 mm
Rod diameter: 12 mm
Force: 1.36, 2.71 kN

... motors and solid thrust rod, which can be operated in harsh working conditions for a long time. Our ball screw adopted the trending planetary ball screw to stimulate ...

Stroke : 10 mm - 3,000 mm
Force: 1,347, 4,642, 361, 722 kN
Torque: 97.44, 2,436, 4,872 Nm

... The lead of Planetary Roller Electric Cylinder can be designed to be smaller than that of Ball Screw Electric Cylinder. The lead of planetary roller electric cylinder ...

Stroke : 250, 300, 420, 280 mm
Force: 1 kN - 300 kN

Ultra-precise electric cylinders, specific for presses How they Work The SA Series electric cylinders offer high thrust force and instant, precise machining control. The versatility of the electrical ...

Force: 0 kN - 50 kN

... Motor Mounts with additional gearboxes. * Available in machine screw and ball screw, precise positioning, and uniform speed. * Standard with 1-start thread screw, ...
