Average luminance 65°.
2MG parabolic louvre, high efficiency, in specular aluminium with superficial titanium‑magnesium treatment, non‑iridescent, with transverse blades closed at the top.
Prismatic methacrylate (PMMA) diffuser for total shielding of the louvre compartment.
Film protective against dust and finger marks, adhesive, attached to louvre.
Direct symmetric distribution.
Lifetime (L80/B10): 100000 h. (tq+25°C)
Photobiological safety RG0.
SOURCE
Linear LED modules.
Colour initial tolerance (MacAdam): SDCM 2.
MECHANICAL
Housing with squared shape in white painted galvannealed steel, with nonreflecting surface.
ELECTRICAL
In compliance with EN 60598‑1.
Compliance with the EN 60598‑2‑22 standard for power supply from a centralised CPSS emergency system must be verified in the technical data sheets of each individual device on our website.
Terminal block for cascade line connection with connection capacity 2x2.5 mm².
INSTALLATION
Ceiling mounted or suspension installation.
Thanks to the full compatibility of dimensions, fixing spacing and accessories with the previous fluorescent version, this product becomes the perfect solution for updating existing installations.
APPLICATIONS
Environments: exhibition areas, staterooms, with VDTs, halls, shops, great halls, offices.
Environments where soft diffuse light is required for optimal visual comfort.
LIGHT MANAGEMENT
The DALI products can be controlled with 3F Easy Dim or 3F Smart Dimming technology.
