Lenses for wide distribution, in transparent methacrylate (PMMA) with external flat surface.
Wide, direct and asymmetric controlled distribution.
Lifetime (L80/B10): 100000 h. (tq+25°C)
Photobiological safety RG0.
L UGR version
Average luminance 65°.
SOURCE
Linear LED modules.
Colour initial tolerance (MacAdam): SDCM 3.
MECHANICAL
Housing in hot‑galvanised steel, painted in white polyester, obtained through rolling process.
Light unit in hot‑galvanised steel, painted in white polyester base with fixing springs and retractable safety hooks in stainless steel.
End caps in white polycarbonate.
Stainless steel mounting brackets with anti‑slip screws.
ELECTRICAL
In compliance with EN 60598‑1.
Compliance with the EN 60598‑2‑22 standard for power supply from a centralised CPSS emergency system must be verified in the technical data sheets of each individual device on our website.
The luminaires with EP permanent emergency wiring on board comply with EN 60598‑2‑22 standard, high risk areas excluded.
INSTALLATION
Ceiling, suspension or wall installation.
APPLICATIONS
Environments: architectural, commercial, transit areas, cornices, boards.
Suitable product for food production plants (HACCP), IFS (Food Version 6), BRC (GSFS Food Version 7).
L UGR version
Environments: exhibition areas, staterooms, with VDTs, halls, shops, great halls, offices.
LIGHT MANAGEMENT
The DALI products can be controlled with 3F Easy Dim or 3F Smart Dimming technology.
