ILLUMINOTECHNICAL
Direct symmetric distribution.
Average luminance 65°.
Lifetime (L75/B10): 100000 h. (tq+25°C)
Photobiological safety RG0.
SOURCE
Linear LED modules.
Colour initial tolerance (MacAdam): SDCM 3.
MECHANICAL
Housing in white painted epoxy‑polyester powder aluminium.
Diffuser in SMP trasparent microprismatic methacrylate (PMMA) externally, anti‑glare with high transmittance.
Perimetral frame in white polycarbonate.
Anti‑fall safety cable.
ELECTRICAL
In compliance with EN 60598‑1.
Multi‑current power supply, to be ordered separately, that allows you to choose the driving current of the fixture at the time of installation according to the required illuminance.
Fixtures in compliance with EN 60598‑2‑22, for power supply from a centralised CPSS emergency system.
Class II.
EP permanent emergency kit, to be ordered separately, compliant with the EN S60598‑2‑22, high risk areas excluded.
INSTALLATION
Lay‑in or pull‑up installation, Ceiling or suspension via accessory.
APPLICATIONS
Environments: with VDTs, meeting rooms, offices.
Environments: recreational, transit areas, corridors, schools, stairwells.
Environments where soft diffuse light is required for optimal visual comfort.
Suitable product for food production plants (HACCP), IFS (Food Version 6), BRC (GSFS Food Version 7).
