- 3X MOTION TECHNOLOGIES CO.,LTD.
Brushless motor 42BYA Seriesthree-phase24 V48 V
Add to favorites
Compare this product
Characteristics
- AC/DC
- three-phase
- Type
- brushless
- Voltage
- 24 V, 48 V, 36 V
- Number of poles
- 4-pole
- Power
Max.: 100 W
(0.136 hp)Min.: 8.4 W
(0.011 hp)- Torque
0.04 Nm, 0.08 Nm, 0.16 Nm
(0.0295 ft.lb, 0.059 ft.lb, 0.118 ft.lb)- Rotational speed
2,000 rpm, 4,000 rpm, 6,000 rpm
(12,566.37 rad.min-1, 25,132.74 rad.min-1, 37,699.11 rad.min-1)
Description
GENERAL SPECIFICATION
Winding type：YWE
Hall effect angle：120 Deg. Electrical angle
Radial play：0.02mm /460g
End play：0.02mm /400g
Max. radial force：15N @ 10mm from the flange
Max. axial force：10N
Insulation class：B
Dielectric strength：500VDC for one minute
Insulation resistance：100MΩ min., 500VDC
