Digital I/O module NXT-M2analogEthernetModbus RTU
Add to favorites
Compare this product
Characteristics
- Signal type
- digital, analog
- Bus
- Ethernet, Modbus RTU, RS485, Modbus, CANbus, Bluetooth
- Number of inputs/outputs
- 2 analog inputs, 2 digital inputs
- Type
- remote
- Mounting
- DIN rail
- Other characteristics
- configurable
Description
I/O acquisition modules with 2 inputs / outputs: NXT-M2
Remote I/O acquisition module compatible with ModBus RTU (RS485) and ModBus TCP (Ethernet) protocols.
I/O module equipped with ModBus and CANBus
NXT-M2 is an IO module with 2 digital inputs and 2 analog inputs.
The I/O and communication ports are galvanically isolated to protect the entire circuit.
Thanks to the configurability of the inputs, each module is versatile and can be used for different types of probes.
Technical features:
2 digital inputs and 2 configurable analog inputs
2 digital outputs
NFC interface for configuration
Optional WiFi / Bluetooth module
ModBus and CANbus I/O devices are specially developed for industrial applications. They are equipped with a DIN rail enclosure and are easy to install.
