CNC lathe XS series

horizontal2-axisdrilling

Standard Features… Multi-repetitive Cycles G70-G76 for automatic finishing, roughing, drilling, threading and grooving cycles Toolpath Graphics for verification of part profile 10.4" Color LCD Display Inch/metric data input Absolute/incremental programming in the same block Thread cutting leads range from 0.00001" to 1.0" Threading retract Variable lead threading Multiple and continuous threading Rigid tapping Constant surface speed/direct rpm programming Menu programming format with operator prompts 2 axes linear and circular interpolation Sequence number search Sequence number comparison and stop 128K part program memory Background editing Extended part program edit 64 sets of tool offsets Optional stop/block delete Run hour part counter Tool nose radius compensation Tool geometry/wear offsets Tool life management Work coordinate system G52-G59 Automatic reference zero return G28 Reference position return check G27 Spindle orientation Machine alarm diagnostic Absolute encoders Manual pulse generator RS 232 interface port Mirror image Turret crash protection Dynamic graphic display Pattern data input Manual intervention and return Chuck/tailstock barrier Latest Fanuc Beta i series spindle and Beta i axis motor
