Oxygen analyzer EASI-1N

carbon dioxideC2H4monitoring

Technology The O2-CO2 analyser is entirely built by ABSOGER and consists of two sensors: Oxygen: A zirconium monoxide cell with 0-5% resolution. CO2: an infrared (NDIR) sensor with 0-5% resolution. Applications Monitoring and managing Controlled Atmosphere chambers Monitoring refrigerated containers Gas detection Analysing fruit respiration Technical specifications Integrated sampling pump. Flow rate: 1 L / minute Oled screen. Response time: depending on the length of the line, generally under 2 min Power supply: internal rechargeable battery under 230 V – 50/60 Hz. Weight: 4 kg. Dimensions: 23 cm x 20 cm x 11 cm high Sample connection diameter: 6/8 O2 sensor: Zirconium oxide cell: Measuring range: 0 to 25% Sensor accuracy: 0.05% up to 1.5% and 0.1% on the rest of the scale Sensor resolution: 0.01 % up to 1.5% and 0.1 % on the rest of the scale CO2 sensor: Infrared adsorption detection (NDIR) Measuring range: 0 to 5% (0-10%, 0-30% and 0-100% optional) Sensor accuracy: 0.05% up to 1.5% and 0.1% on the rest of the scale Sensor resolution: 0.01 % up to 1.5% and 0.1 % on the rest of the scale
