Analog output module USB-DA12-8E

USB8-channelautomation

-High-speed USB 2.0 device -Up to 125K conversions per DAC per second -Streaming waveform data at over 400,000 DAC outputs per second total -128K Sample buffer on-board, or Infinitely long streaming waveforms! -Buffered waveforms at up to 1 million DAC conversions per second total -ILDA compatible -Small, portable 8-channel, 12-bit, digital to analog outputs -Double-buffered allowing simultaneous update of all DACs -Analog output ranges of 0-2.5V, 0-5V, 0-10V, ±2.5V, ±5V, ±10V -Single-ended and differential outputs on separate connectors -PC/104 module size and mounting compatibility -Rugged small-sized (4″ x 4″ x 1.25″) steel enclosure -Type B USB connector features industrial strength and high-retention design -Designed, made, supported, and manufactured in the USA Factory Options -Resistors in series with differential connector for impedance matching -DIN rail mounting provision -Economy ‘E’ version available without screw terminal board -OEM (board only) version with PC/104 mounting holes and PCB footprint for added flexibility in embedded applications -RoHS Available. Please contact us for ordering information USB 8 Channel Analog Output Module The USB-DA12-8A is an ideal solution for adding portable, easy-to-install analog outputs to any computer with a USB port. The USB-DA12-8A is a USB 2.0 device, offering the highest speed available with the USB bus. It is fully compatible with both USB 1.1 and USB 2.0 ports. The board is plug-and-play allowing quick connection whenever you need additional I/O on a USB port.
