Vertical disc grinding machine ART.52
workpieceautomatichigh-precision

Vertical disc grinding machine - ART.52 - ACETI MACCHINE - workpiece / automatic / high-precision
Vertical disc grinding machine - ART.52 - ACETI MACCHINE - workpiece / automatic / high-precision
Vertical disc grinding machine - ART.52 - ACETI MACCHINE - workpiece / automatic / high-precision - image - 2
Add to favorites
Compare this product


Characteristics

Type
vertical disc
Applications
workpiece
Control type
automatic
Other characteristics
high-precision
Spindle speed

950 rpm
(5,969 rad.min-1)

Power

4 kW
(5.44 hp)

Description

Power supply 400 | 50 | 3 Volt|Hz|Phase Acoustic emission 70 dB Overall dimension (Width x Depth x Height) 1000 x 1300 x H. 1450 mm Weight standard machine 370 kg Abrasive disc grinder unit Abrasive disc dimension ø 800 mm Peripheral speed 40 m/sec Support table dimension 1000 x 300 mm Support table revolution 0 ÷ + 45 ° Standard Equipments Machine respect CE stamp of compliance - Machine with CE conformity mark made respecting the requirements of the most recent directives concerning it. - Machine complete with instruction manual complete with CE conformity certificate, test sheet and exploded view with relative spare parts list. - Machine equipped with a set of service keys suitable for the adjustment and maintenance of the machine. Base Strong base with anti-vibration rubbers at the base and a useful shelf for tools inside. Electrical panel Low voltage electric controls with padlock device integrated in the main electric switch. Electronic brake card Emergency stop with electronic motor braking with safety anti-reset function. Support plane Support plane details inclinable with adjustable height. Disc Aluminium disc perfectly balanced. Abrasive disc Abrasive disc mounted on the machine ready for use. Belt grinder cover Carter sander with predisposition connection system.
