Plate beveling machine ART.01

electricstationaryautomatic

Power supply 400 | 50 | 3 Volt|Hz|Phase Acoustic emission 68 dB Overall dimension (Width x Depth x Height) 1000 x 700 x H. 1300 mm Weight standard machine 210 kg Chamfer - bevel unit Bevel dimension (diagonal) 0 ÷ 8 mm Milling cutter diameter ø 110 mm Quantity of widia insert milling cutter 10 No. Widia insert type/code SPUN 19 04 08 ISO Support table dimension 120 x 1000 mm Peripheral speed 8 - 16 m/sec Standard Equipments Machine respect CE stamp of compliance - Machine with CE conformity mark made respecting the requirements of the most recent directives concerning it. - Machine complete with instruction manual complete with CE conformity certificate, test sheet and exploded view with relative spare parts list. - Machine equipped with a set of service keys suitable for the adjustment and maintenance of the machine. Base Strong base with anti-vibration rubbers at the base and a useful shelf for tools inside. Electrical panel Low voltage electric controls with padlock device integrated in the main electric switch. Electronic brake card Emergency stop with electronic motor braking with safety anti-reset function. Motor Motor 2 speeds Hardened guide coating Rectified and grooved guides with hardening treatment for a prolonged friction resistance. Axial movement Axial displacement for full use of the cutting surface of the inserts. Handwheel Handwheel for chamfer dimension adjustment. Miller body Milleler body complete with 10 tungsten carbide inserts.
