Band sawing machine BS 940 RS3”verticalwoodautomatic
Add to favorites
Compare this product
Characteristics
- Technology
- band
- Orientation
- vertical
- Treated material
- wood
- Operational mode
- automatic
- Other characteristics
- hydraulic, with automatic feeder
Description
MATERIALS
Solid wood
MANUFACTURINGS
Cut
MAXIMUM CUTTING HEIGHT
550,00 mm
MAXIMUM CUTTING WIDTH
910,00 mm
BLADE WIDTH
min 50 - max 90 mm
OVERALL DIMENSIONS
1710x1880x2860mm
STANDARD EQUIPMENT
CE
· 400V/3/50 self-braking motor
· Front emergency stop acted by cable
· Rear push-button emergency stop
· Solid flywheels (1/3 crowned in the front) without rubber
· Bronze scrapers on flywheels
· Gravity-fed blade lubrication system on felt pad
· Automatic star-delta starter
· Blade tension gauge
· Wooden insert upper/lower saw blade guide
· Rack and pinion blade guide raising with incorporated blade
NOT CE
· 400V/3/50 motor
· Manual star-delta starter
· Solid flywheels (1/3 crowned on front), without rubber
· Bronze scrapers on flywheels
· Gravity-fed blade lubrication system on felt pad
· Blade tension gauge
· Wooden insert upper and lower saw blade guides
· Rack blade guide lifting with incorporated blade protection
· Foot brake
