STANDARDS OF MANUFACTURE
EN 1092-2 DRILLING FLANGES
CEN/TC 144 SC1
MATERIALS
BODY EN GJS-400-15 DUCTILE IRON EN 1563
COVER EN GJS-400-15 DUCTILE IRON EN 1563
STEM AISI304 STAINLESS STEEL EN 10088-1
WHIRLING ABS
SET SCREWS A2-70 STAINLESS STEEL EN 10088-1
CORROSION PROTECTION
COATED INSIDE-OUTSIDE
(FBE) EPOXY 250 MICRONS
CERTIFIATES
D.M. NR.174 – HEALTH DEPARTMENT (I)
TESTING
EN 12266-1 (ISO 5208) PRESSURE TESTS
ACCESSORIES
FIG.701R-701AR IMPULSE EMITTING DEVICE
INSTALLATION HORIZONTAL / VERTICAL
