Analog output card APCIe-3521

digital4 analog outputs8 analog outputs

The PCI-Express analog output board APCIe-3521 has 8/4 analog outputs, 16-bit, and 8 digital I/O, 24 V. The board is especially suited for applications in the sector of industrial process control, measurement technology and monitoring, for example for the control of chemical processes etc. in the harsh industrial environment. Features Analog outputs Voltage or current outputs 16-bit resolution (15-bit for 0-10 V) Output ranges: ±10 V, 0-10 V (through software) Output voltage after reset: 0 V Each output has its own ground line (without optical isolation) Output current ±5 mA max. for voltage outputs Current outputs: 0-20 mA, min. load 10 Ω, max. load 560 Ω, at 20 mA EMI filters Digital 4 dig. inputs including 1 interruptible input 4 dig. outputs, 24 V, optically isolated Timer / Watchdog 2 timers of which 1 can be used as a watchdog
