Analog input module MSX-E3011

digitalEthernetsafety

The Ethernet analog input system MSX-E3011 has 16 analog differential inputs, 16-bit, voltage or current inputs. 4 channels can be acquired simultaneously with 100 kHz. The system was especially developed for data acquisition and processing close to the test object in the harsh industrial environment and has a robust normed metal housing with the degree of protection IP 65. It has an extended temperature range from -40°C to +85°C. The ARM®9 32-bit processor allows the calculation of the acquired values. The Development Mode allows to customise applications individually. Through synchro connection, several MSX-E systems can be cascaed and synchronised with one another in the µs range. Features 24 V digital trigger input ARM®9 32-bit processor 64 MB onboard SDRAM for storing data Robust standardized metal housing Power Save Mode: Reduced power consumption when no acquisition runs Analog inputs 16 diff. inputs, 16-bit, 5-pin M12 female connector Sampling frequency max. 100 kHz, up to 4 simultaneous channels Input ranges: ± 5 V, ± 10 V (16-bit) | 0-5 V, 0-10 V (15-bit) Current inputs optional Safety features Status LEDs for fast error diagnostics Optical isolation Input filters Overvoltage protection ± 40 V Internal temperature monitoring
