M-Bus converter HD67044-B2-20ModbusDIN rail
Add to favorites
Compare this product
Characteristics
- Bus
- M-Bus, Modbus
- Other characteristics
- DIN rail
Description
Ports: - 1xM-Bus; 1xPROFINET
Data Rates M-Bus - Up to 38400 bps
Data Rates PROFINET - 100 Base-T Autosensing
M-Bus connector - 2way 5mm fixed screw terminal
PROFINET connector - RJ45
Power supply - 15...21V AC ; 18...35V DC
Operating temperature - -40°C/+85°C (-40°F/+185°F)
Dimensions - 106x58x95 (DxWxH)
Weight - 200g approx
Mechanical fixing - DIN Rail montage
Software - SW67044
