Specifications:
Ports: 1xCAN 2.0; 2xOptic Fibres
CAN2.0 connector: Terminal block
Optic Fibres connector: ST 820 um
DATA rates CAN2.0 Up to 1 Mbps
DATA rates optic Fibres 1Mbps
Serial connector: 3way 5mm terminal block
Ethernet connector RJ45
Power supply connector 2way 5mm removable screw terminal
Power supply 8…24V AC; 12…35V DC
Operating temperature -40°C/+85°C (-40°F/+185°F)
Dimensions 120x23x107 mm(DxWxH)
Weight 200g approx
Mechanical fixing DIN Rail montage
SOFTWARE SW67221FSX
ORDER CODE HD67221FSX
