ProfiNet converter HD67606-A1CANDIN rail
Add to favorites
Compare this product
Characteristics
- Bus
- ProfiNet, CAN
- Other characteristics
- DIN rail
Description
Specifications:
Ports: 1xCAN; 2xPROFINET
Data Rates CAN Up to 1Mbps
Data Rates PROFINET 100 Base-T Autosensing
CAN connector 3way 5mm terminal block
PROFINET connector RJ45
Power supply 8…24V AC; 12…35V DC
Power supply connector 2way 5mm terminal block
Operating temperature -40° to +85° (-40°F to +185°F)
Dimensions 120x23x107 (DxWxH)
Weight 200g approx
Mechanical fixing 35mm DIN Rail montage
Software SW67606
ORDER CODE: HD67606-A1
