Batch counter CS2-CT

digitalRS485Modbus

5 Digits Multifunction Counter (Pulse Input) (96x48mm) The CS2-CT provides high speed and multifunction, counting, control and communication (Modbus RTU mode) of Pulse from flow meter or encoder, proximity switch, photo switch for length control. There are 3 external control input (DI) in standard and the optional 4 Relay, 1 Analogue,and RS485 port available. They are also support N, R, C mode for totalizer control. Summary of specifications: ● Measuring Pulse 0.01Hz~20KHz(optional: over 20KHz~50KHz); Contact / NPN / PNP / Voltage Pulse can be switch on rear of meter ● 4 banks pre-set for all relay functions relative 4 difference application, and selectable by 3 External Control ● Inputs(E.C.I.) or front key in optional ● 4 relay can be individual programmed for N/R/C mode and energized time. ● 3 external control input can be individual programmed for Reset, Gat ● Analogue Output and RS485(Modbus RTU mode) available in option ● Comply to CE standard & RoHS
