Double-sided adhesive tape AT528conductiveshieldingfor EMI shielding
Add to favorites
Compare this product
Characteristics
- Type
- double-sided, conductive, shielding, for EMI shielding
- Backing
- copper
- Adhesive
- acrylic
- Other characteristics
- high temperature-resistant, removable
- Applications
- for electrical applications
- Thickness
0.05 mm
(0 in)- Operating temperature
Min.: -20 °C
(-4 °F)Max.: 155 °C
(311 °F)
Description
Conforms to military specification MIL-T-47012, BS EN 60454 – Part 2, ASTM D – 1000 and to the flame retardant requirements of UL 51
AT528 is a 50 micron copper foil coated with a conductive thermosetting solvent based acrylic adhesive supplied on a removable silicone release liner.
Suitable for EMI / RFI and static shielding, this tape can be easily soldered and withstands extreme low and high temperature (from -20°C to +155°C). It is also easy to unwind for a quicker application.
AT528 has been tested in accordance with:
ASTM D-1000 and meets BS EN 60454 – Part 2 test methods (formerly VDE 0340, BS 3924).
The tape has also been tested and meets flame retardency requirements of UL 510 (UL guide OANZ 2, File number E 86214 (M).
• Easy unwind
• Easily soldered
• High and Low Temperature Resistant
• Electrically conductive thermosetting acrylic adhesive
• Used for EMI / RFI and static shielding
