Gas analyzer MIRA Pico

natural gascarbon monoxidecarbon dioxide

Introducing the MIRA Pico portable middle infrared laser-based gas analyzers from AerisTechnologies, Inc. MIRA gas analyzers utilize simple and robust direct absorption spectroscopy using high resolution tunable lasers, enabling target species to be measured in real-time with sub-ppb sensitivity, ppb level accuracy, and high specificity. The MIRA Pico analyzers provide performance levels previously only achieved in much larger, heavier, and higher power consumption gas analyzers. Our current list of Pico instruments includes: Natural Gas (CH4, C2H6, and H2O) Formaldehyde (H2CO and H2O) Carbon Monoxide and Nitrous Oxide (CO, N2O, and H2O) Carbon Dioxide and Nitrous Oxide (CO2, N2O, and H2O) Carbonyl Sulfide (OCS, CO2, and H2O) Acetylene (C2H2 and H2O) The MIRA Pico portable analyzers utilize a compact, pressure stabilized sensor core to achieve high sensitivity and low drift, significantly reducing or eliminating calibration requirements in many field applications. It is the only gas analyzer in its class that includes a smart power routing circuit and a battery pack. Like a smartphone or a laptop, switching back and forth between the internal battery and a power outlet is effortless, providing thus the user with a never-seen-before ease of use for an instrument of this class. Key Features Ultra-portable: 11.5” x 8” x 3.75” Under 3 kg (6 lbs) with batteries Ready to measure one minute after pressing the start button Full absorption spectrum always visible Ultra small 60 cc cell volume for instantaneous response and sharp signals when measuring transients
