Diaphragm valve VFA - FL/TC
pneumatically-operatedfor controlfor liquid food products and beverages

diaphragm valve
diaphragm valve
diaphragm valve
Add to favorites
Compare this product


Characteristics

Type
diaphragm
Operation
pneumatically-operated
Function
for control
Media
for liquid food products and beverages
Body
seat
Applications
tank bottom
Other characteristics
aseptic
DN

Max.: 100 mm
(3.937 in)

Min.: 25 mm
(0.984 in)

Pressure

Max.: 10 bar
(145 psi)

Min.: -1 bar
(-14.5 psi)

Temperature

Max.: 200 °C
(392 °F)

Min.: -80 °C
(-112 °F)

Description

The Aseptic valve functions primarily for food or pharmaceutical processing. It is suitable for direct installation in tanks and reactors preparation. Aseptic valves can be manual or pneumatic, with sizes that range from 3/4" to 2" in AISI 316L stainless steel. It is also made with a silicone diaphragm ensured to have complied with the Food and Drug Administration's standards. This valve is available in two versions, the Flanged type valve with a removable body, and the Butt-weld directly welded onto the tank. Each version of the Aerre Inox aseptic valve has its own functions specifically configured to satisfy the needs of various applications. The Aseptic Valve with Flanged body is made with a built-in mechanical/inductive control box.

Catalogs

VA-VFA.
VA-VFA.
6 Pages
