Radial Brinell hardness tester with built-in milling
EASYFLAG 3000 is a special Brinell hardness tester, with built-in milling, designed to overcome the typical problems of radial drills, which are not suited to bear loads higher than 3000 kg together with the force for blocking the parts, nor to resist the vibrations caused by milling.
Manufactured by Easydur AFFRI Group.
TEST LOADS
from 10 kgf to 3000 kgf (98.07 to 29421 N)
BRINELL HBWT ISO 6506 / ASTM E-10
HBW 1/10 – HBW 1/30 – HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – 2.5/187.5 – 5/25 – 5/62,5 – 5/125 – 5/250 – 5/750 – 10/100 – 10/250 – 10/500 – 10/1000 – 10/1500 – 10/3000
Rockwell and superficial Rockwell ISO 6508 / ASTM E-18
HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR / HRN – HRT
CONVENTIONAL BRINELL TEST
The standard Brinell test in most forges and steel factories consists in testing of big parts with previous surface preparation to remove rust and scales from the samples. It is common to use a grinding disk to manually polish the surface but this method overcomes some problems like heating of the material, removing material to an unknown depth, production of metal dust, and huge spending of time.
The sample is then carried under the Brinell hardness tester which can de manual or automatic and the indent generated has to be read with a microscope to calculate the result.
THE SOLUTION: EASYFLAG
Easyflag Brinell hardness testing machine is a fully automatic system that perform all the measuring procedure with just one button:
Automatic research and contact with the sample
Auto-milling at programmed depth
Auto indenting and loading
Automatic reading with autofocus
