Press decoiler-straightener L series

The AIDA L Series Combined Uncoiler and Straightener provides total integration with the press for a high-performance line. With 13 hard chrome plated work rolls, 6 upper and 7 lower, as well as, auto-control of the straightener speed which reduces roll / stop marks (when used with the AIDA F-III NC Roll Feeder), the L Series helps to optimize your stamping production. Able to process material 0.3 mm - 3.2 mm thick and 30 mm - 400 mm wide, the L Series can be integrated into a wide variety of press operations. AIDA L Series Combined Uncoiler Straightener Features Superior straightening capabilities: 13 work rolls (6 upper, 7 lower) All rolls are plated with hard chrome Auto-control of straightener speed The straightener runs continuously, thereby preventing roll (stop) marks (when used in combination with the F-III Series NC Roll Feeder) Straightener speed is controlled by loop arm inverter controls The straightener's upper feed roll section opens up wide to allow easy access to the rolls for cleaning A manual handle is used for drum expansion/contraction A manual handle is used to adjust the drum sideplates Coil position adjustments are made using the manual movable sideplates Double uncoiler versions are also available
