Rotary vane compressor Comp-3™ seriesbreathing airACon casters
Add to favorites
Compare this product
Characteristics
- Technology
- rotary vane
- Type
- breathing air
- Power source
- AC
- Portability
- on casters
- Lubrication
- oil-lubricated
- Application domain
- industrial
- Pressure
110 psi
- Power
1.49 kW
(2.03 hp)
Description
Rotary vane air compressor rated for continuous duty
Pressure range to 110psi output
2 HP electric motor, 1750rpm continuous duty - thermally protected
115/230 VAC 1-phase, 60Hz, 17.2 amps (Requires 20amp service)
Low maintenance - 500 hours between oil changes
10" pneumatic tires
50,000 hour minimum vane life
Built-in skid plate for stair climbing
USDA approved food grade oil in compression end
Automatic pressure unloading - full modulation air control
Breather Box™ Grade-D filtration package required
Noise level below 70 dbA at 3 feet
8 Gallon Twin-Air™ tank assembly, 8.5cf air storage @ 110psi, ASME coded
1/2" 5000 series Hansen style coupling on air outlet
Optional explosion-proof motor (230/3 VAC only), Model TA-3EXP
Dimensions: 46"L x 24"W x 22"H
Weight: 150 lbs.
