Tank with mixer ASS-TK1403-ME

accumulationstainless steelcylindrical

Accumulation station with stainless steel tank with satin finish and anti-sediment convex bottom. The integrated agitator allows homogenization of all fluid contents with a specialized axial-radial paddle. The integrated level detection device allows the percentage management of the incoming fluids for the "blending" to be prepared and subsequently to be dispensed to the process. Equipment essential characteristics: – AISI 316 stainless steel tank – Flanged top cover with inspectionable opening incoming fluid multiple connections: n.2 G1″ (F) + n.1 G1.½” (F) – Electric motor mixer with 4 inclined blades with special geometry – AISI 316 stainless steel level detector with facing ceramic membrane DIMENSIONS MATERIALS AND POWER: Tank product contact material: AISI 316 stainless steel Propeller mixer Specialized four-blade impeller dia. 300mm Mixer with Screw Reducer Kit SF 1,5 kw (20 – 70 rpm) Total tank dimensions: dia 730 mm x h. 1812mm Fluid quantity in the tank about 400 lt Mixing fluids: primers - water based / solvent based paints pure solvents - reactive - protective - release agent. Main options: – Control unit for connection to level detector and on/off consents – Pilot operated valves for process fluid replenishment – Atex version available – Available version for food sector (tank + mixer) – Power station with pump and filters 237200-EM05Px
