Scroll compressor SRK2airelectrically-poweredstationary
Add to favorites
Compare this product
Characteristics
- Technology
- scroll
- Type
- air
- Power source
- electrically-powered
- Portability
- stationary
- Lubrication
- oil-free
- Application domain
- industrial, for medical applications
- Flow
14.4 m³/h
(508.53 ft³/h)- Power
2.2 kW
(2.99 hp)
Description
Overpressure [MPa] 0,8
Efficiency [m³/h] 14,4
Efficiency [l/min] 240
Weight [kg] 340
Dimension (axbxc) [mm] 1500x608x1172
Tank capacity [l] 240
Compressed air connection G 1/2
Compressed air connection height dimension (d) [mm] 385
Ambient temperature [°C] from 5 to 40
Air temperature on the outlet [°C] approx.10 above ambient temperature
Noise level L [dB(A)] 54
Motor power [kW] 2,2
Motor rotational speed [rpm] 3000
Feed voltage [V] 400
