Fiber optics distributor MDB EasyPatch-FO

IP20DIN rail

• Equipped with 12x E-2000 APC Singlemode Simplex fiber optic couplers • 4x cable feed (2x M25 from top and 2x M25 from bottom) • Suitable for vertical or horizontal cable feeding • Optimal bending radii inside the housing • Easy mounting of the modules due to removable front panel • Suitable for vertical or horizontal mounting on a din rail • Screw-off side panel for user-friendly installation, maintenance and expansion • Simple exchange of the modular front panels • The keystone front panel can be equipped with different keystone capable modules • High quality powder coated surface • Simple port numbering optionally available • Front panel 12-port keystone • Material steel, 1,5mm • Weight housing approx. 870g • Temperature resistance -20°C to +70°C • IP protection IP20 • Color grey, powder coated RAL7016 • Housing dimensions 112 x 86,6 x 136,2 mm Scope of delivery: • 12x E-2000 APC Singlemode simplex coupler • 12x Keystone adapter for F.O. modules • 1x MDB DRM housing, grey RAL7016 • 1x MDB DRM front panel 12-port keystone • 1x DIN rail mounting clip • 2x M25 cable gland, 13-18mm • 2x M25 blind plug • 4x lock nut
