Three-phase electric energy meter UEC1P5-D

DIN rail50 Hzwith LCD display

6A three phase 3/4 wire energy counter Highlights •For 1 or 5A CT •Programmable CT ratio •Fully bi-directional four quadrants measurements for all energies and powers •For 3 / 4 wire networks with balanced or unbalanced load •Class B according to EN 50470-3 •Tariff input •2 S0 outputs for energy pulse emission •LCD display with 8 main digits •Optical port for communication with external modules •Available with MID certification Applications •Totalization of the electric energy in the industry for each single line or machine. •Measurement of energy generated by renewable sources such as solar, eolic, etc. •Accounting and billing of consumptions in camp sites, malls, residential areas, naval ports, etc. •Totalization of the electric consumption in hotels, congress centers, exhibition fairs. •Accounting of the consumptions in buildings with executive office services. •Internal allocation of the consumptions in timeshare civilian and industrial buildings. •Realization of energy monitoring systems. •Remote survey of the consumptions and compute of the costs. Technical features Power supply •Power supplied from the voltage circuit •Nominal measurement voltage ±20% •Max consumption (for each phase): 7,5 VA - 0,5 W •CT burden (for each phase): 0,04 VA •Nominal frequency: 50/60 Hz Voltage & frequency •Nominal values: A) 3x230/400 V 50 Hz B) 3x240/415 V 50 Hz C) 3x230/400 V 50/60 Hz D) 3x230/400...3x240/415 V 50/60 Hz Current •Starting current Ist: 2 mA •Minimum current Imin: 10 mA •Transitional current Itr: 50 mA •Reference current Iref (In): 1 A •Maximum current Imax: 6 A
