Compressed air pressure regulator R13
for oxygenpistonsingle-stage

compressed air pressure regulator
compressed air pressure regulator
Add to favorites
Compare this product


Characteristics

Product
for compressed air, for oxygen
Technology
piston
Number of stages
single-stage
Material
brass
Applications
for pneumatic applications
Other characteristics
miniature, line
Pressure

Max.: 10 bar
(145.04 psi)

15 bar
(217.56 psi)

Min.: 2 bar
(29.01 psi)

Flow

Max.: 300 l/min
(79.25 us gal/min)

Min.: 300 l/min
(79.25 us gal/min)

Description

R13 - In-line pressure regulator, 2 to10 bar, factory setted, G1/4 ported Description In-Line pressure regulator with factory-set outlet pressure, reducing from e.g. 10 bar to 5 bar. The regulator R13 is suited for basic pressure control only with an outlet pressure tolérance of ± 30%. The outlet pressure stated below is valid for 12 bar inlet pressure. For other inlet pressure please refer to the according item from the diagram. Benefits •Higher safety through lower pressure. Tools and equipment protected against pressure damages. •Cost réduction through substantially reduced air consumption. Longer service life. •Noise réduction for tools. Media compressed air or non-corrosive gases Supply pressure max. 15 bar Adjustment Select the pressure regulator according to the desired outlet pressure. The outlet pressure cannot be subsequently adjusted. This safeguards against tampering. Relieving function non-relieving, therefore not recommended for applications such as nailers Température range 0 °C to 60 °C / 32 °F to 140 °F, for appropriately conditioned compressed air down to -30 °C / -22 °F Material Body: brass Elastomer: NBR/Buna-N, optionally FKM ________________________________________________________________________________________________________x
