Compressed air pressure regulator 233
for inert gasescartridgesingle-stage

Add to favorites

Compare this product

Go to the ALPHA AUTOMATISMES Sarl website for more information

Characteristics

Product

for compressed air, for inert gases

Technology

cartridge

Number of stages

single-stage

Material

brass

Applications

industrial, pneumatic

Other characteristics

compact, miniature

Pressure

12 bar
(174.05 psi)

Max.: 12 bar
(174.05 psi)

Min.: 0 bar
(0 psi)

Flow

Max.: 350 l/min
(92.46 us gal/min)

Min.: 0 l/min
(0 us gal/min)

Description

Cartridge pressure regulator suitable for assembly block. Media: compressed air or non-corrosive gases Supply pressure: max. 12 bar Adjustment: Select the pressure regulator according to the desired outlet pressure. The outlet pressure cannot be subsequently adjusted. This safeguards against tampering. Relieving function: non-relieving Temperature range: -20 °C to 60 °C / -4 °F to 140 °F Material Body: brass Piston: brass Elastomer: NBR Filter: stainless steel
