Blow-off nozzle RRHfor cleaningcompressed airstainless steel
Add to favorites
Compare this product
Characteristics
- Function
- for cleaning, blow-off
- Fluid
- compressed air
- Material
- stainless steel, aluminum
- Other characteristics
- rotary, orientable
- Orifice diameter
0.8 mm, 1.2 mm, 1.5 mm, 1.8 mm
(0.031 in, 0.047 in, 0.059 in, 0.071 in)- Flow
Min.: 95 l/min
(25.1 us gal/min)Max.: 375 l/min
(99.06 us gal/min)- Pressure
4 bar, 6 bar, 8 bar
(58 psi, 87 psi, 116 psi)
Description
"Hurricane" is a dynamic rotating blast nozzle that cleans surfaces quickly and effectively thanks to the shockwave generated by the sweep of compressed air at a frequency of 9 Hz.
The angle of the 2 jets can be adjusted independently forwards, sideways and backwards. A choice of 4 jet powers is available with a rotating head diameter of 50 or 70 mm.
It is ideal for robotised cleaning operations in production, where a single-axis movement of the nozzle is sufficient.
The nozzle can be coupled to an ionisation system to remove electrostatic charges.
Catalogs
No catalogs are available for this product.
See all of ALPHA AUTOMATISMES Sarl‘s catalogs
