Portable gaussmeter ASMGM

The Air Shipment Milligauss Meter has been designed so that one person alone can be the tester, and do repackaging, if necessary, without moving from the area. The remote sensor, shown on the right side, is connected through a 15-foot cable to the control box (left). This control box is placed next to both the package and the tester (person) so the tester can manually rotate the shipment. The remote sensor is placed either 15 feet or 7 feet away, depending on which test is being done. Using knobs on the control box, the meter is first set to zero without the air shipment present. This compensates for the field in the room (including the earth's field). This zero adjust remains accurate until the sensor is moved or if something large and magnetic is moved nearby. After zeroing, the package is brought in and rotated (in a lazy Susan manner) 360° on the floor. As the package is rotated, the tester is watching to see if the display ever reads over 5.25 or -5.25 milligauss, or 2.00 or -2.00, depending on which test is being done. With the fast update speed of the numerical display, the whole test requires about 20 seconds, including 360° rotation.
