PXI switch module EX7204

VXIrelaydigital

• Combine up to 16 SPDT or 8 multiport, high-performance relays in a 2U footprint • Latching/Terminated options (EX7204L) • LXI/LAN and USB command and control options • Embedded web interface provides interactive utility to monitor and control relays from anywhere in the world • Flexible API supports IVI and Linux development environments minimizing software investment • LXI trigger event implementation provides seamless test synchronization with external devices • Store up to 128 relay configurations for quick recall, including automatic power-up state The EX7204 series offers maximum performance, flexible design options, and an operating range that extends to 26.5 GHz – all in a compact footprint. Any combination of SPDT, SP4T and SP6T building blocks can be housed in a single 2U-rack enclosure that includes an 8-bit digital I/O bus. The standard EX7204A high-density mainframe houses non-latching/non-terminated relays, while the EX7204L is used for applications that require the performance of latching and terminated relays. The EX7204 series software architecture allows easy integration with other GPIB, PXI, VXI, LXI or USB instruments. The software drivers are based on the IVI industry standard and can be used within virtually any development environment. A graphical, web-based interface provides the necessary tools for controlling and monitoring an EX7204 series through local or remote access using a web browser.
