Linear array leak tester LT1

pressurefor bottlesfor full containers

Leak tester LT1 is based on an AND&OR electronicequipment Its main mechanical characteristics are: 1. Metallic structure built in stainless steel. 2. Lateral test conveyors, adjustable in positionthanks to a manual wheel or knob, which allows its adjustment without using any tools. 3. Fairing and protection according to the 2006/42/EC standard. Working principle Its working principle is based on thecalculation of the pressure gradient,measured laterally when the bottleis passing through the machine bytwo charge photocells of 5-15kgwith 6,000 divisions (detecting leaksup to ø0.1mm in 1L bottles). Thisalso allows the self-checking theequipment without being affected byany atmospheric changes. Application • Detection of cap defects or wrong capping. • Detection of bottle leaks. The command central unit has the following generalcharacteristics: • Automatic calibration. • Parameters programming by touch panel: rejection delays and timings, type of bottle, maximum leak level allowed, conveyor speed (external or internal), etc. • Display of production data, number of good or defective bottles, leak levels in each test and maximum level allowed. • Light warning in case of several consecutive defective bottles. • Sensibility of 2g – equivalent to ø0.1mm leak in 1L bottles. • Rejection unit for leaking bottles to be installed at the input of the test conveyor.
