Compact housing SBS®X-75A

rectangularplasticfor connectors

SBS®X-75A RECEPTACLE HOUSING • SBS®X-75A Sealed Waterproof Connector Series comes with two power contacts rated up to 135A, along with up to 4 auxiliaries. • Connector accepts power wire sizes from 12 to 4 AWG (2.5 to 25mm2) and wire sizes 24 to 14 AWG (0.50 to 1.5 mm2) for auxiliaries • Operating temperature -20°C to 105°C (-4°F to 221°F) • Handles up to 5,000 mating cycles • Product is rated for IP 68 ingress protection certification thru the use of O-Rings and Grommets in the mated condition, or with the use of covers in the unmated condition • Positive metal latches help safeguard against accidental disconnects that may be caused by vibration • Built in cable clamp allows for strain relief on wires
